Part Number: 42-352-02
Manufacturer: Extron
Condition: New
Height: 3.0" (7.6 cm)
Analog line level input: 1 unbalanced line level audio from analog captive screw input (stereo)
Audio codecs: OPUS
Baud rate and protocol: 300 to 115200 baud (9600 baud = default) 8 (default) or 7 data bits 1 (default) or 2 stop bits No parity (default), even or odd parity
Baud rate and protocol (RS-232): 300 to 115200 baud (9600 baud = default) 8 (default) or 7 data bits 1 (default) or 2 stop bits No parity (default), even or odd parity
Bit depths: 16-bit or 24-bit
CMRR: >60 db typ @ 1 kHz
Chroma sampling: 4:4:4, 4:2:2, or 4:2:0
Chroma sampling1: 4:4:4, 4:2:2, or 4:2:0
Color bit depth: 8, 10, 12 or 16 bits per color
Color bit depth1: 8, 10, or 12 bits per color
Communication: WebRTC
ConferenceShare™: ShareLink Pro ConferenceShare™ for Windows® ShareLink Pro ConferenceShare™ for macOS®
Connector: 1 shielded female RJ-45 connector
Connectors: 2 shielded female RJ-45 connectors (ShareLink Pro 2500)
Container (if included): MPEG-2 TS (MPEG-2 part 1 or ISO/IEC 13818-1 or ITU-T Rec. H.222.0), MP4 (MPEG-4 part 14 or ISO/IEC 14496-14) including mp4, m4a, m4v file extensions and compatible containers*, WAV (containing LPCM audio)
Cooling: Fan (air flows top to sides); vents on sides
Crosstalk: <-80 dB, at 1 kHz, fully loaded
Data rate: 10/100/1000Base-T, half/full duplex with Auto-detect
Decoder input: 1 embedded digital audio from decoder (stereo)
Default settings – LAN A: DHCP = ON Default static IP settings if DHCP is switched OFF: Link speed = Auto-detected Duplex level = Auto-detected IP address = 192.168.253.254 Subnet mask = 255.255.255.0 Gateway = 0.0.0.0 DNS: 0.0.0.0
Default settings – LAN B: DHCP = Off Default static IP settings: Link speed = Auto-detected Duplex level = Auto-detected IP address = 192.168.254.254 Subnet mask = 255.255.255.0 Gateway = 0.0.0.0 DNS: 0.0.0.0
Device: 24.4 watts
Device and power supply: 28.4 watts
Digital outputs: 250 mA sink from 24 VDC max.
Enclosure dimensions: 1.0" H x 8.75" W x 8.0" D (1" high, half rack wide, 8" deep)(2.54 cm H x 22.2 cm W x 20.3 cm D)(Depth excludes connectors)
Enclosure type: Metal
Ethernet data rate: 10/100/1000Base-T
Formats: RGB and YCbCr digital video
Frame rate: 30 fps
Frame rate1: 24, 25, 30, 50, or 60 fps
Frame rates: 24, 25, 30, 50, or 60 fps
Frequency response: 20 Hz to 20 kHz, ±0.5 dB
Furniture mount: Yes, with optional mounting kit
Gain: 0 dB
Gain error: ±0.1 dB channel to channel
HDMI input: 1 embedded digital audio from HDMI (stereo)
Horizontal frequency: 15 kHz to 135 kHz
IR output carrier frequency: 30 kHz to 300 kHz
Image codecs: BMP, JPG, PNG, TIFF
Image file formats: BMP, JPG, PNG, TIFF
Impedance: >10k ohms balanced/unbalanced
Input gain adjustment: -18 dB to +24 dB, 1 dB steps
Input impedance: ≥10k ohms typical
Input voltage range: 0 to 24 VDC
Max. video data rate: 18 Gbps (6 Gbps per color)
Maximum built-in USB hubs: 0
Maximum current source (12 VDC powered): 900 mA Range = 825mA/902mA/989mA [min/typ/max]
Maximum current source (PoE+ powered): 500 mA Range = 448mA/502mA/562mA [min/typ/max]
Maximum data rate: 10.2 Gbps (3.4 Gbps per color)
Maximum level (Hi-Z): +21 dBu at rated THD+N when gain is set to 0 dB, balanced.
Maximum pixel clock: 600 MHz
Minimum built-in USB hubs: 0
Network file share protocols: CIFS/SMB (SMB 1.0, NT LM 0.12), NFS
Network interface controllers (NICs): 2
Nominal level: +4 dBu, -10 dbV configurable
Number/signal type: 1 H.264/AVC digital video and AAC audio over IP
Operating systems: Windows 10 and later Apple® macOS 12.0 and later
Optional built-in USB hubs: 0
Output resolutions (pass-through mode): 640x480, 800x600, 1024x768, 1280x720, 1280x724, 1366x768, 1600x1200, 1920x1200, 3840x2160, 4096x2160 (up to 60Hz), 480i, 480p, 576i, 576p, 720i, 720p, 1080i, 1080p, 2K, 4K @ 60Hz
Output resolutions (window mode): 640x480, 800x600, 1024x768, 1280x720, 1280x724, 1366x768, 1600x1200, 1920x1200, 3840x2160, 4096x2160 (up to 60Hz), 480i, 480p, 576i, 576p, 720i, 720p, 1080i, 1080p, 2K, 4K @ 60Hz
Peripheral device power: 200 - 250mA
Pin configuration: Tx, Rx, and GND
Power input: 12 VDC from external power supply (PS 1242 sold separately) or Power over Ethernet 802.3at (PoE+)
Power over Ethernet (PoE): Complies with 802.3at (PoE+), class 4 (type 2)
Product warranty: 3 years parts and labor
Product weight: 1.65 lbs (0.75 kg)
Programmable pullup: 2k ohms to +5 VDC
Protocols: DHCP, DNS, HTTP, HTTPS, ICMP, IEEE 802.1X, NTP, SFTP, SMTP, SNMP, SSH, TCP/IP, UDP/IP, SMB v1, SMB v2, SMB v3
Pull streams: RTP/RTCP (RFC 3550), RTSP (RFC 2326), interleaved RTSP (RTP/RTSP), RTP/RTSP tunneled through HTTP
Push streams: MPEG-2 TS/UDP (ISO/IEC 13818-1), MPEG-2 TS/RTP (RFC 2250), Direct RTP (RFC 3984)
Quantity/type: 1 bidirectional RS-232
Rack mount: Yes, with optional rack shelf kit Back-of-rack mountable with optional back-of-rack mounting kit
Regulatory compliance: CE, c-UL, UL, C-tick, FCC Class A, ICES, VCCI Complies with appropriate requirements of RoHS and WEEE
Resolution: Up to 4096x2160
Resolution range: 2560 x 1600 @ 60 Hz or 1080p @ 60 Hz 4K UHD (3840x2160) @ 30 Hz
Resolution range (Pass-through mode): 640x480 @ 60 Hz to 4096x2160 @ 60 Hz (includes 480i, 480p, 576i, 576p, 720i, 720p, 1080i, 1080p, 2K, 4K)
Resolution range (Window mode): 640x480 @ 60 Hz to 3840x2160 @ 30 Hz (includes 480p, 576p, 720p, 1080p, 2K, 4K)
S/N: >90 dB, at maximum balanced output (unweighted)
Sampling rate: 48 kHz
Security: HTTPS, DTLS v1.2
ShareLink™ Pro: ShareLink Pro for Windows® ShareLink Pro for macOS®
Signal Type: HDMI 2.0b, HDCP 2.3
Software: ShareLink Pro for Android™ ShareLink Pro for iOS
Standards: DVI 1.0, HDMI 2.0, HDCP 2.3
Stereo channel separation: >80 dB @ 1 kHz
Stream discovery: SAP (RFC 2974), SDP (RFC 4145, RFC 4566)
THD + Noise: <0.01%, 20 Hz to 20 kHz at nominal level
Temperature/humidity: Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing Operating: +32 to +104 °F (0 to +40 °C) / 10% to 90%, noncondensing
Threshold high to low: <2.0 VDC
Threshold low to high: >2.8 VDC
Transport: TCP, UDP, RTP, multicast or unicast
USB data rates: Low speed (1.5 Mbps), full speed (12 Mbps), high speed (480 Mbps), SuperSpeed (5 Gbps)
USB standards: USB 2.0, USB 1.1, USB 1.0 compatible
Vertical frequencies (pass-through mode): 24 Hz to 75 Hz
Vertical frequencies (window mode): 23.98 Hz, 24 Hz, 25 Hz, 29.97 Hz, 30 Hz, 50 Hz, 59.94 Hz, 60 Hz
Vertical frequency: 24 Hz to 75 Hz
Vibration: ISTA 1A in carton (International Safe Transit Association)
Video codecs: VP8
Video file formats: 264, AVI, M2T, M2TS, M4V, MKV, MOV, MP4, MPG, SDP, TS
Volume control: -100 dB to 0 dB (control 0-100 in 1 dB steps, default: -30 dB)
Web browsers: Google Chrome 80.0 and later
