Extron RSB 129 (part number 60-604-02) — the gray powder coat 1U Basic Rack Shelf for 9.5-inch deep products.

Nine and a half inches of tray in a single rack unit makes this the workhorse of Extron's basic shelf range. It accepts any practical mix of 1U half-rack, quarter-rack and eighth-rack width Extron products across its 17.5-inch usable span, and each one is bolted down from below with the screws Extron includes. The shelf itself is steel, powder-coated in the standard Extron gray so it disappears into a rack of matching hardware. This is the basic version rather than the RSU 129 kit, so blanking faceplates are not in the box — order RFF Series plates if you need the unused positions covered.

Key Capabilities

• 1U steel shelf with 9.5-inch (24.1 cm) depth
• Mixes half-, quarter- and eighth-rack width devices on one tray
• 19-inch rack width, 17.5 inches of usable shelf
• Products fix from the underside using the supplied hardware
• Gray powder coat finish matching Extron rack products
• Optional RFF Series faceplates close off empty positions

Where It Is Used

Deep racks in control rooms, command centres, broadcast and post facilities, university AV closets, simulation suites and medical imaging systems, where a full-depth rack still needs one organised unit for scalers, extenders and audio interfaces.

Specifications at a Glance

• Model: Extron RSB 129, part number 60-604-02
• Rack height: 1U, 1.73 in (4.4 cm)
• Width: 19 in (48.25 cm) with rack ears, 17.5 in (44.5 cm) usable
• Depth: 9.5 in (24.1 cm); steel construction
• Finish: gray powder coat; false faceplates not included

Also referenced as Extron RSB129, RSB-129, part number 6060402.
