Extron RSB 126 (part number 60-604-10) — the black 1U Basic Rack Shelf for 6-inch deep products. Extron lists this part number as retired.

The RSB 126 is the mid-depth member of Extron's basic shelf range, sized for devices with a 6-inch or 3-inch footprint. In one rack unit it will carry two half-rack-width products, four quarter-rack-width products, or eight eighth-rack-width products, and it can be fitted at either the front or the rear of the rack depending on where the cable runs land. Construction is metal, weight is 1.8 lbs, and Extron rates it to RoHS and WEEE with a three-year parts and labour warranty. As a basic shelf, blanking plates are not supplied — the RSU 126 kit is the version that includes them.

Key Capabilities

• 1U shelf sized for 6-inch and 3-inch deep Extron products
• Holds two half-rack, four quarter-rack or eight eighth-rack devices
• Mountable at the front or rear of the rack
• Metal construction, 1.8 lbs (0.8 kg)
• Meets applicable RoHS and WEEE requirements
• Three-year Extron parts and labour warranty

Where It Is Used

Mid-depth equipment racks in boardrooms, lecture halls, control rooms, houses of worship and command centres, plus rear-of-rack builds where interfaces sit close to the field cabling rather than at the front panel.

Specifications at a Glance

• Model: Extron RSB 126, part number 60-604-10
• Rack height: 1U, 1.73 in (4.4 cm); width 19 in (48.25 cm) with rack ears
• Depth: 6.5 in (16.5 cm)
• Weight: 1.8 lbs (0.8 kg); metal enclosure
• Warranty: 3 years parts and labor; RoHS and WEEE compliant

Also referenced as Extron RSB126, RSB-126, part number 6060410.
