Extron Retractor USB-C Pro 8K Retraction Module
- • Extron Retractor USB-C Pro 8K module
- • USB-C to USB-C, 3 ft (90 cm) of travel
- • Tested to exceed 7,500 cycles
- • Sales, replacement and exchange
- • Part# 70-1065-56 / 70106556
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Extron Retractor USB-C Pro 8K (part number 70-1065-56) - the highest-bandwidth cable in the Retractor Series, rated for 8K video over a single USB-C connection.
This is the red ring member of the USB-C Retractor family. It runs DisplayPort Alternate Mode across all four lanes at HBR3, which is what lifts the maximum video data rate to 32.4 Gbps and makes 7680x4320 at 30 Hz possible. The same cable also charges the source at up to 60 watts. Note that its USB data path is specified at USB 2.0 speeds: the design trades peripheral bandwidth for video headroom.
Key Capabilities
- Supports 7680x4320 (8K) at 30 Hz with 4:4:4 chroma sampling at 8 bits per color.
- 4K modes include 4096x2160 at 60 Hz with 12-bit color and 3840x2160 at 120 Hz at 8 bit.
- DisplayPort Alt Mode using DP 1.4 over 4 lanes at up to HBR3, 8.1 Gbps per lane - 32.4 Gbps total.
- Signal handling up to DisplayPort 1.4 with HDCP 2.3; frame rates from 24 through 120 fps.
- Charges the connected device at up to 60 W with 3 A maximum current.
- USB data path is specified as USB 2.0 and USB 1.1 compatible at up to 480 Mbps, with no built-in hub.
Where It Is Used
Executive boardrooms driving very high resolution displays, design and post-production suites, simulation and visualisation labs, and medical imaging review rooms where pixel density carries clinical meaning. The red ring lets an installer identify this cable instantly in an enclosure holding several USB-C modules.
Specifications at a Glance
- Connector type: 1 USB-C male to 1 USB-C male, 3 feet (90 cm) of travel
- Enclosure: metal and plastic, 22.7" H x 1.2" W x 4.7" D (57.7 x 3.0 x 11.9 cm)
- Product weight: 2.8 lbs (1.3 kg); tested to exceed 7,500 cycles
- Mounts into Extron Cable Cubby, TLP Cable Cubby TouchLink and AVEdge 100 enclosures and the TMK 120 R Table Mount Kit, all sold separately
- Regulatory compliance: RoHS, WEEE
Frequently asked questions about the Extron Retractor USB-C Pro 8K USB-C Retraction Module
Does Ampronix sell the Extron Retractor USB-C Pro 8K USB-C Retraction Module?
Yes. Ampronix is an authorized Extron distributor and sells the Extron Retractor USB-C Pro 8K USB-C Retraction Module (70-1065-56). Call Ampronix for a quote.
Does Ampronix offer replacement and exchange for the Extron Retractor USB-C Pro 8K USB-C Retraction Module?
Yes. Ampronix provides sales, replacement and exchange for the Extron Retractor USB-C Pro 8K USB-C Retraction Module. Call Ampronix for a quote.
Is the Extron Retractor USB-C Pro 8K USB-C Retraction Module listed under other names?
Yes. The Extron Retractor USB-C Pro 8K USB-C Retraction Module is also referenced as Extron RetractorUSBCPro8K, Retractor-USB-C-Pro-8K, part number 70106556.
What are the key features of the Extron Retractor USB-C Pro 8K USB-C Retraction Module?
Key points: Supports 7680x4320 (8K) at 30 Hz with 4:4:4 chroma sampling at 8 bits per color; 4K modes include 4096x2160 at 60 Hz with 12-bit color and 3840x2160 at 120 Hz at 8 bit; DisplayPort Alt Mode using DP 1.4 over 4 lanes at up to HBR3, 8.1 Gbps per lane - 32.4 Gbps total; Signal handling up to DisplayPort 1.4 with HDCP 2.3; frame rates from 24 through 120 fps. Call Ampronix to confirm details for your application.
Also referenced as Extron RetractorUSBCPro8K, Retractor-USB-C-Pro-8K, part number 70106556.
