Extron One USB 2.0 Type-A Connector to Captive Screw MAAP 70-312-51
Extron One USB 2.0 Type-A Connector to Captive Screw MAAP 70-312-51
Extron One USB 2.0 Type-A Connector to Captive Screw MAAP Module
- • RAL9010 White finish for colour-matched Extron plate arrays
- • USB 2.0 Type-A receptacle wired to a 4-pin captive screw terminal
- • Single-space MAAP plate, Extron Quick Connect module type
- • Published pin order: 1 +5 V (Vbus), 2 Data-, 3 Data+, 4 ground
- • Terminates on site from a standard USB A-to-B or A-to-mini-B cable
- • Retired by Extron; part 70-312-51 under product ID IN9467
- • Fits Extron interfaces, MAAP frames and other MAAP-ready products
Product discontinued.
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Extron One USB 2.0 Type-A Connector to Captive Screw (part number 70-312-51) — the RAL9010 White finish of Extron's single-space MAAP USB plate, retired from the current Extron line and stocked by Ampronix for legacy work.
Extron indexes this module as product ID IN9467 and prints 70-312-51 against the RAL9010 White colour. The plate carries a USB 2.0 Type-A receptacle on the front and a four-pin captive screw terminal on the back, so the cable behind the panel is landed by hand rather than plugged in. Extron's wiring card sets out the method: remove the Type-B or mini-B end from a standard USB lead, strip about 0.5" (1.3 cm) of jacket, check each conductor with an ohm meter, then land +5 V (Vbus), Data-, Data+ and ground on pins 1 through 4.
Key Capabilities
- RAL9010 White finish, one of the colours Extron published for this module
- USB 2.0 Type-A receptacle wired through to a 4-pin captive screw terminal
- Extron Quick Connect module in the single-space MAAP size
- Published pin order: +5 V (Vbus), Data-, Data+, ground
- Fits Extron interfaces, MAAP mounting frames and other MAAP-ready products
- Retired by Extron — held for colour-matched spares and legacy replacements
Where It Is Used
Extron places MAAP modules in walls, tables, podiums, floor boxes and equipment racks. Buyers of this particular suffix are usually keeping an existing plate array consistent — replacing a damaged USB position in a boardroom table box, or completing a spares kit for a training suite that was built out in RAL9010 White throughout.
Specifications at a Glance
- Signal: USB 2.0
- Connectors: one USB Type-A receptacle to one 4-pin captive screw terminal
- Module type: Quick Connect
- Module size: single space (MAAP)
- Finish: RAL9010 White
The USB length limits Extron prints on the wiring card still govern the cable you terminate: 16 feet 4.8 inches (5.0 m) between full-speed devices, 9 feet 10 inches (3.0 m) for low-speed devices.
Also listed as Extron IN9467, One-USB-2.0-Type-A-Connector-to-Captive-Screw, part number 7031251.
