Manufacturer: Extron | Model: PowerCage 401 FOX DT HD MM | Part number: 70-1092-11 (also written 70109211)

The Extron PowerCage 401 FOX DT HD MM (70-1092-11) is a new dual-port multimode fiber HDMI transmitter module available through Ampronix for the PowerCage 401 enclosure. Each module contains two independent FOX HDMI transmitters, sending HDMI video, audio, and control up to WUXGA (1920x1200) to remote receivers over multimode fiber. HDCP compliant, hot-swappable. Singlemode version: 70-1092-12.

Key capabilities

• Two independent FOX HDMI transmitter ports per module, hot-swappable in PowerCage 401
• Sends pixel-for-pixel HDMI images up to WUXGA (1920x1200) over multimode fiber
• HDMI audio embedding and de-embedding with analog stereo outputs
• Auto-Input Memory, real-time status monitoring, RS-232 insertion via enclosure
• Singlemode version: 70-1092-12

Where it is used

Equipment rooms sending HDMI signals from local sources to remote displays over multimode fiber in broadcast facilities and campus AV systems.

Specifications at a glance

• Ports: 2 x multimode fiber HDMI transmitter
• Max resolution: WUXGA (1920x1200)
• Compatible enclosure: PowerCage 401
• Warranty: 3-year product, 7-year Everlast power supply

Frequently asked questions

• Is the Extron PowerCage 401 FOX DT HD MM 70-1092-11 available new or refurbished? - Ampronix stocks the PowerCage 401 FOX DT HD MM (70-1092-11) as a new unit through its authorized Extron distribution agreement.
• What receiver pairs with the PowerCage 401 FOX DT HD MM at the display end? - The 70-1092-11 transmitter pairs with the FOX DR HD MM (70-1092-21) receiver module in a second PowerCage 401 or with standalone FOX HDMI receivers over multimode fiber.
• Does Ampronix offer support for the Extron PowerCage 401 FOX DT HD MM? - Yes. Ampronix provides repair, exchange, and replacement services for the PowerCage 401 FOX DT HD MM and the broader Extron FOX fiber extender line.

Ampronix is an authorized Extron distributor. Need support for your Extron PowerCage 401 FOX DT HD MM? Ampronix offers professional repair, exchange, and replacement services for this product and the broader Extron line.

Also referenced as Extron PowerCage401FOXdtHDmm, PowerCage-401-FOX-DT-HD-MM, part number 70109211.
