Extron PCC-2 18/500 (part number 22-275-02) — black 500 ft spool of PendantConnect hybrid cable for SF 26PT and SF 28PT SoundField pendants.

This is the bulk-reel form of Extron's heavier PendantConnect cable, jacketed in black. A single PVC outer jacket contains the 18 AWG speaker pair together with two galvanized steel wire ropes, so a cut length off this reel is simultaneously the amplifier circuit and the mechanical support for the pendant it feeds. At 500 ft (152 m) per spool, a contractor can serve a whole zone of SF 26PT or SF 28PT enclosures from one purchase and match every drop to its measured ceiling height.

Key Capabilities

• 500 ft (152 m) spool in black, with sequential footage marking on the jacket.
• Two galvanized steel safety cables, 3/64 in with 7x7 stranding, inside the jacket.
• Tensile strength rated 30.9 MPa minimum on the safety cable system.
• 18 AWG copper pair, 16/30 stranding, red and black conductors.
• Minimum bend radius 1.86 in; nominal core OD 0.079 in (2.0 mm).
• Non-plenum PVC construction, NEC AWM, 80 °C, CPR compliant.

Where It Is Used

Black jacketing is the usual answer under exposed structure and dark decks — arenas and gymnasiums, industrial and brewery interiors, black-box and studio spaces, open-plenum offices and back-of-house retail where SF 26PT and SF 28PT pendants are distributed across a large floor plate.

Specifications at a Glance

• Model / part: PCC-2 18/500, 22-275-02
• Standard length: 500 ft (152 m) spool, black
• Safety cables: 2, galvanized steel wire rope, 7x7
• Minimum bend radius: 1.86 in
• Conductor DCR: 6.2 ohms/1,000 ft (20 ohms/km)

Also referenced as Extron PCC-218/500, PCC-2-18-500, PCC218500, part number 2227502.
