Extron PCC-2 18/500 (part number 22-274-02) — 500 ft white spool of PendantConnect cable for SF 26PT and SF 28PT pendant speakers.

Large-format pendant jobs rarely share one drop height, which is why PCC-2 is also sold by the reel. This part number is 500 ft (152 m) of the two-support-cable construction in a white jacket. Inside a single PVC outer jacket sit an 18 AWG twisted pair for audio and a pair of galvanized steel wire ropes rated to 30.9 MPa minimum tensile strength. Footage printing along the jacket lets a crew measure, cut and dress each drop from the same reel without second-guessing what is left.

Key Capabilities

• Standard spool length 500 ft (152 m); white jacket, sequentially numbered.
• Two integrated galvanized steel safety cables, 3/64 in, 7x7 stranding.
• Minimum safety-cable tensile strength 30.9 MPa.
• One 18 AWG twisted pair, 16/30 stranded copper, 0.048 in (1.20 mm).
• Nominal DC resistance 6.2 ohms per 1,000 ft (20 ohms/km); nominal core OD 0.079 in (2.0 mm).
• Minimum bend radius 1.86 in; non-plenum PVC; NEC AWM, 80 °C, CPR compliant.

Where It Is Used

Reach for the spool on multi-speaker distributed systems: airport and rail concourses, convention centres, museums, university commons and worship auditoriums where SF 26PT and SF 28PT pendants hang at staggered heights under pale or white ceilings.

Specifications at a Glance

• Standard length: 500 ft (152 m) spool, white
• Conductors: 1 twisted pair, 18 AWG copper, red and black
• Safety cables: 2 (3/64 in galvanized steel wire rope, 7x7)
• Safety-cable tensile strength: 30.9 MPa minimum
• Compatible speakers: Extron SF 26PT and SF 28PT

Also referenced as Extron PCC-218/500, PCC-2-18-500, PCC218500, part number 2227402.
