Extron PCC-1 18/500 (part number 22-270-02) — a 500 ft white spool of PendantConnect hybrid speaker cable for SF 3PT installs cut to length on site.

Buying PendantConnect by the spool is what makes a multi-speaker pendant job practical: every drop is a different height, and cutting from bulk beats stocking a dozen fixed lengths. This part supplies 500 ft (152 m) of the PCC-1 construction in a white jacket. The audio pair and the steel wire rope safety cable travel inside one PVC outer jacket, so each length pulled off the reel already contains both the electrical path and the support member. Sequential footage printing along the jacket makes measuring off the spool a one-person job.

Key Capabilities

• 500 ft (152 m) standard spool length, white jacket, cut to any drop height.
• One 18 AWG twisted pair, 16/30 stranded copper, 0.048 in (1.20 mm) per conductor.
• Single galvanized steel wire rope safety cable, 1/32 in, 1x19 stranding.
• Safety cable rated to a minimum tensile strength of 10.3 MPa.
• Nominal conductor DC resistance 6.2 ohms per 1,000 ft (20 ohms/km).
• Minimum bend radius 1.7 in; non-plenum PVC; NEC AWM, 80 °C, CPR compliant.

Where It Is Used

Spooled PCC-1 suits build-outs where SF 3PT pendants sit at varied heights across one space — university lecture theatres, convention and ballroom areas, transit halls, retail concourses and worship rooms. Light ceilings and painted structure are where the white jacket earns its place.

Specifications at a Glance

• Standard length: 500 ft (152 m) spool
• Conductors: 1 twisted pair, 18 AWG copper, red and black
• Safety cables: 1 (1/32 in galvanized steel wire rope)
• Minimum bend radius: 1.7 in
• Jacket colour: white, sequentially numbered

Also referenced as Extron PCC-118/500, PCC-1-18-500, PCC118500, part number 2227002.
