Extron One USB 2.0 Type-A Connector to Captive Screw MAAP Module
- • Extron One USB 2.0 Type-A captive screw MAAP white
- • USB 2.0 Type-A to 4-pin captive screw terminal
- • Pin order: +5 V, Data-, Data+, ground
- • Sales, replacement and exchange
- • Part# 70-312-21 / 7031221
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Manufacturer: Extron; Model: One USB 2.0 Type-A to Captive Screw MAAP (White); Part number: 70-312-21 (also written 7031221)
The Extron One USB 2.0 Type-A to Captive Screw MAAP White (70-312-21) is a new single-space MAAP Quick Connect module available through Ampronix. Identical in function to the black 70-312-11, white plate finish. A USB 2.0 Type-A receptacle on the face wires to a four-pin captive screw terminal on the rear (pin 1: +5 V Vbus; pin 2: Data-; pin 3: Data+; pin 4: ground). Fits Extron MAAP mounting frames. White finish for light-color plate arrays.
Key capabilities
- USB 2.0 Type-A receptacle to 4-pin captive screw terminal; Quick Connect MAAP module
- Field-terminated from any standard USB lead; no soldering required
- Pin order: +5 V (Vbus), Data-, Data+, ground
- White single-space MAAP metal plate; fits Extron MAAP mounting frames
- USB length limits: 16.4 ft (5.0 m) full-speed, 9.8 ft (3.0 m) low-speed
Where it is used
Classrooms, training rooms, and meeting spaces with light-finish walls and plate hardware where a field-terminated USB host port needs to blend with white decor.
Specifications at a glance
- Signal: USB 2.0; module: single-space MAAP, metal; finish: white
- Warranty: 3-year Extron parts and labor
Frequently asked questions about the Extron One USB 2.0 Type-A Connector to Captive Screw MAAP
Is the Extron USB 2.0 Type-A MAAP 70-312-21 available new or refurbished?
Ampronix stocks the 70-312-21 as a new unit through its authorized Extron distribution agreement.
What is the difference between the white 70-312-21 and the black 70-312-11?
Both are functionally identical Quick Connect USB 2.0 MAAP modules; the 70-312-21 has a white plate and the 70-312-11 has a black plate.
Does Ampronix offer replacement and exchange for Extron MAAP connectivity modules?
Ampronix supplies a full range of Extron MAAP and AAP connectivity modules and replacement parts.
Ampronix is an authorized Extron distributor and carries a full range of Extron MAAP and AAP connectivity modules.
Also listed as Extron IN9467, One-USB-2.0-Type-A-Connector-to-Captive-Screw, part number 7031221.
