Extron One USB 2.0 Type-A Connector to Captive Screw MAAP 70-312-41
Extron One USB 2.0 Type-A Connector to Captive Screw MAAP 70-312-41
Extron One USB 2.0 Type-A Connector to Captive Screw MAAP Module
- • Extron One USB 2.0 Type-A captive screw MAAP Inline White
- • USB 2.0 Type-A to 4-pin captive screw terminal
- • Inline White finish, retired by Extron
- • Sales, replacement and exchange
- • Part# 70-312-41 / 7031241
Product discontinued.
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Manufacturer: Extron; Model: One USB 2.0 Type-A to Captive Screw MAAP (Inline White); Part number: 70-312-41 (also written 7031241)
The Extron One USB 2.0 Type-A to Captive Screw MAAP Inline White (70-312-41) is a single-space MAAP Quick Connect module available through Ampronix in Inline White finish. Retired from the current Extron line; stocked by Ampronix for existing Inline White plate installations requiring like-for-like replacement. Identical in function to the active black (70-312-11) and white (70-312-21) variants. USB 2.0 Type-A receptacle to 4-pin captive screw terminal; pin 1: +5 V Vbus; pin 2: Data-; pin 3: Data+; pin 4: ground.
Key capabilities
- Inline White finish - matches existing Inline White Extron plate assemblies
- USB 2.0 Type-A receptacle to 4-pin captive screw terminal; Quick Connect MAAP module
- Field-terminated from any standard USB lead; no soldering required
- Retired by Extron - stocked by Ampronix for legacy color-match replacements
- Fits Extron MAAP mounting frames and MAAP-ready products
Where it is used
Legacy Inline White plate assemblies in boardrooms, classrooms, and lecterns where a damaged USB module needs to be replaced without changing the plate color scheme.
Specifications at a glance
- Signal: USB 2.0; module: single-space MAAP, metal; finish: Inline White (retired)
Frequently asked questions about the Extron One USB 2.0 Type-A Connector to Captive Screw MAAP
Is the Extron USB 2.0 Type-A MAAP 70-312-41 available?
Ampronix stocks the 70-312-41 for legacy color-match replacements; contact Ampronix to confirm current availability.
Why is the 70-312-41 listed as retired?
Extron discontinued the Inline White finish; the currently active color options are black (70-312-11) and white (70-312-21). The 70-312-41 is stocked by Ampronix for sites with existing Inline White plate assemblies.
Does Ampronix offer replacement and exchange for Extron MAAP connectivity modules?
Ampronix supplies a full range of Extron MAAP and AAP connectivity modules including current and legacy variants.
Ampronix is an authorized Extron distributor and carries a full range of Extron MAAP and AAP connectivity modules, including legacy color variants.
Also listed as Extron IN9467, One-USB-2.0-Type-A-Connector-to-Captive-Screw, part number 7031241.
Related: Extron products, Video Solutions.
