Extron HSA 400 (part number 60-700-1B) — UK AC outlet with a brushed aluminum top plate, in Extron's tilt-up Hideaway surface access enclosure.

Specify this build when the furniture finish calls for brushed aluminum rather than black, and the room is wired to UK standards. The enclosure is metal, routed into the tabletop and secured from below with a clamshell bracket. Its top plate latches shut nearly level with the surface; press it and a gas lift carries the connector panel up to a 49-degree angle, presenting an AC outlet, two RJ-45 jacks and whatever AAP connectors the project calls for.

Key Capabilities

• Brushed aluminum top plate measuring 10.11 in by 6.42 in at the outer rim
• One unswitched UK-pattern AC receptacle
• Four single-space or two double-space Extron AAP positions on the faceplate
• Two CAT 6 RJ-45 jacks terminated to TIA/EIA T568B
• Gas lift rated at 100,000 open and close cycles
• Installs in work surfaces 0.38 in to 1.75 in thick

Where It Is Used

UK boardrooms, higher-education lecture theatres, NHS and corporate training rooms, and console furniture in control and dispatch centers. The brushed aluminum finish blends into light-toned or metal-trimmed tables where a black anodized plate would stand out.

Specifications at a Glance

• Surface cutout: 9.64 in W x 5.95 in D
• Tilt plate: 8.16 in W x 4.48 in D
• Weight: 8.4 lbs (3.8 kg)
• Compliance: CE, RoHS, WEEE
• Warranty: 3 years parts and labor

Also referenced as Extron HSA400, HSA-400, part number 607001B.
