Extron HRP 104 AAP (part number 60-1251-30, retired) — a black 1U half-rack-width panel that carries up to four single-space or two double-space Architectural Adapter Plates (AAPs).

The panel installs into a half-rack-width pair of rails spaced 8.85" (22.5 cm) apart, which the integrator supplies and mounts separately; Extron does not include the rails themselves. AAPs are secured into the panel's slots with the nuts supplied with each AAP before the assembled panel is mounted to the rails with four #10-32 screws. Any unused AAP slots can be closed with single-space (70-090-11) or double-space (70-090-12) blank AAP plates, both sold separately. AAPs themselves are also sold separately and chosen to match the signal, power, or network connectivity each installation requires.

Key Points

• Holds up to four single-space or two double-space AAPs
• Mounts to rails spaced 8.85" (22.5 cm) apart, supplied by the integrator
• Secures with four #10-32 screws with captive washers
• Unused slots close with 70-090-11 (single) or 70-090-12 (double) blank AAP plates

Also referenced as Extron HRP104AAP, HRP-104-AAP-60-1251-30, part number 60125130.
