Extron HDMI DVI-D/12 (part number 26-614-03) — a 12 ft (3.6 m) HDMI male to single link DVI-D male cable, the longest of the thin-gauge lengths in the series.

Twelve feet is the boundary in Extron's own construction table: at this length and below the cable uses 28 AWG conductors and a slim 0.22 in jacket; above it Extron moves to 24 AWG and a thicker build. That makes the /12 the most flexible cable in the range that still spans a real distance, which is why it is the default choice for reaching a wall-mounted display from a credenza or a ceiling projector from a short drop. Shielding is aluminium/Mylar foil per pair plus an overall tinned copper braid.

Key Capabilities

• Single link HDMI male to DVI-D male, DVI 1.0 compliant, gold-plated contacts.
• Data rate to 4.95 Gbps supporting 1920x1200 at 60 Hz and 1080p/60.
• 28 AWG tinned copper conductors and drain wire.
• 0.22 in (5.7 mm) outer diameter with a 0.80 in (20 mm) bend radius.
• Pair impedance 100 ohms plus or minus 10 ohms.
• Attenuation under 10 dB per 10 m at 0.825 GHz.
• UL Listed as type CM, CSA FT-1, UL CL2.

Where It Is Used

The workhorse length for meeting rooms, digital signage cabinets, radiology reading stations and equipment racks that need to reach a display across a desk or up a wall without stepping into the heavier long-run construction.

Specifications at a Glance

• Length: 12 ft (3.6 m)
• Skew: intrapair 151 ps or less per 5 m; interpair 2.42 ns or less per 5 m
• HDMI plug: 1.76 in L x 0.78 in W x 0.44 in thick
• DVI-D plug: 1.92 in L x 1.55 in W x 0.60 in thick
• Warranty: Limited Lifetime Performance

Also referenced as Extron HDMIDVID12, HDMI-DVI-D-12, part number 2661403.
