Extron HC 402 HDMI Wallplate Collaboration System
- • Black decorator-style HDMI wallplate transmitter with matching HCR 102 receiver
- • One STP run carries video, audio and power up to 230 ft (70 m)
- • Selectable output rates from 640x480 to 1920x1200, 1080p and 2048x1080
- • On-board control processor with Ethernet, RS-232, IR and 4 digital I/O
- • Second HDMI input on the receiver for a permanently installed source
- • System power draw of 17.2 watts, 19.6 watts with the supply included
- • Extron 3-year parts and labor warranty; 7 years on the Everlast supply
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Extron HC 402 (part number 42-285-02) — the black decorator-style wallplate build of Extron's compact transmitter-and-receiver collaboration system.
Functionally this is the same system as its white counterpart, finished in black for darker millwork and lectern faces. An HCT 101 D plate accepts one HDMI source where the presenter sits; an HCR 102 half-rack receiver near the display handles scaling and drives the screen. The two link over a single shielded CATx run that also delivers power to the plate, so no mains supply is required inside the wall box. A further HDMI connector on the receiver is available for a fixed room source such as a wireless collaboration gateway.
Key Capabilities
- Single HDMI at the plate, a second HDMI at the receiver, and automatic cable equalization on both.
- Output rates are selectable between 640x480 and 1920x1200, and include 1080p and 2048x1080.
- One STP cable run of up to 230 ft (70 m) moves picture, sound and power, using T568B termination.
- Control processing on board: 10/100Base-T LAN, RS-232, IR emitter port and four digital I/O.
- De-embedded stereo appears on a 5-pole captive screw output at up to +15 dBu balanced.
- Handles DVI 1.0, HDMI 1.4 and HDCP 1.4 sources, processed at 10 bits for 1 billion colors.
Where It Is Used
Dark-finish boardrooms, huddle spaces, lecture podiums, training rooms and clinical conference areas where the wallplate should disappear into the surface. The receiver hides under the table on its pre-attached MBU 125 brackets or sits behind the display using an optional rack shelf.
Specifications at a Glance
- Transmitter: HCT 101 D, 1 female HDMI type A
- Twisted pair reach: 230 ft (70 m)
- Audio S/N: greater than 90 dB at maximum balanced output
- Transmitter weight: 0.2 lb (0.1 kg)
- Warranty: 3 years parts and labor
Also referenced as Extron HC402, HC-402, part number 4228502.
