Manufacturer: Extron | Model: FOX T USB Extender Plus HID MM | Part number: 60-1526-11 (also written 60152611)

The Extron FOX T USB Extender Plus HID MM (60-1526-11) is a new multimode fiber transmitter available through Ampronix for HID-restricted USB extension. It connects to the USB host, forwards HID-class USB signals only over multimode fiber at distances up to 500 m on OM3/OM4, and enforces device class filtering so only keyboards, mice, and smart card readers traverse the link. Pairs with the FOX R USB Extender Plus HID MM (60-1526-21).

Key capabilities

• HID device class filtering at the transmitter: blocks non-HID devices from the link
• Multimode fiber transmitter, 850 nm, extends to 500 m on OM3/OM4
• Peripheral emulation for reliable host boot without a locally attached keyboard
• Pairs with FOX R USB Extender Plus HID MM (60-1526-21)
• Quarter-rack metal enclosure, convection cooled

Where it is used

Secure AV environments where the host-end needs HID-only USB transmission over campus multimode fiber infrastructure.

Specifications at a glance

• Fiber: 2 LC connectors, multimode, 850 nm, up to 500 m on OM3/OM4
• Host connector: USB Type B female
• Enclosure: 1.0 in H x 4.3 in W x 6.0 in D, quarter rack

Frequently asked questions

• Is the Extron FOX T USB Extender Plus HID MM 60-1526-11 available new or refurbished? - Ampronix stocks the FOX T USB Extender Plus HID MM (60-1526-11) as a new unit through its authorized Extron distribution agreement.
• What receiver does the FOX T USB Extender Plus HID MM pair with? - The 60-1526-11 pairs with the FOX R USB Extender Plus HID MM (60-1526-21) at the peripheral end; for singlemode fiber, use the 60-1526-12 transmitter with the 60-1526-22 receiver.
• Does Ampronix offer support for the Extron FOX T USB Extender Plus HID MM? - Yes. Ampronix provides repair, exchange, and replacement services for the FOX T USB Extender Plus HID MM and the broader Extron FOX USB extender line.

Ampronix is an authorized Extron distributor. Need support for your Extron FOX T USB Extender Plus HID MM? Ampronix offers professional repair, exchange, and replacement services for this product and the broader Extron FOX line.

Also referenced as Extron FOXTUSBExtenderPlusHIDMM, FOX-T-USB-Extender-Plus-HID-MM, part number 60152611.
