Manufacturer: Extron | Model: FOX R USB Extender Plus HID SM | Part number: 60-1526-22 (also written 60152622)

The Extron FOX R USB Extender Plus HID SM (60-1526-22) is a new singlemode fiber receiver available through Ampronix for HID-restricted USB extension. It receives USB signals from the matching FOX T USB Extender Plus HID SM transmitter over singlemode fiber at up to 30 km and restricts the link to HID-class peripherals only. Multimode version: 60-1526-21.

Key capabilities

• HID device class filtering: allows only keyboards, mice, and smart card readers on the link
• Singlemode fiber receiver, 1310 nm, extends to 30 km over singlemode fiber
• Built-in 4-port USB 2.0 hub, 500 mA shared
• Pairs with FOX T USB Extender Plus HID SM (60-1526-12)
• Quarter-rack metal enclosure, convection cooled

Where it is used

Multi-building campuses, government facilities, and secure environments where HID peripherals must reach across fiber runs too long for multimode.

Specifications at a glance

• Fiber: 2 LC connectors, singlemode, 1310 nm, up to 30 km
• USB ports: 4 x USB 2.0 Type A female, 500 mA shared
• Enclosure: 1.0 in H x 4.3 in W x 6.0 in D, quarter rack

Frequently asked questions

• Is the Extron FOX R USB Extender Plus HID SM 60-1526-22 available new or refurbished? - Ampronix stocks the FOX R USB Extender Plus HID SM (60-1526-22) as a new unit through its authorized Extron distribution agreement.
• How far can the singlemode HID receiver extend USB signals compared to the multimode version? - The singlemode 60-1526-22 reaches up to 30 km over singlemode fiber, compared to 500 m on OM3/OM4 for the multimode 60-1526-21 — making it suitable for inter-building deployments across a large campus or campus cluster.
• Does Ampronix offer support for the Extron FOX R USB Extender Plus HID SM? - Yes. Ampronix provides repair, exchange, and replacement services for the FOX R USB Extender Plus HID SM and the broader Extron FOX USB extender line.

Ampronix is an authorized Extron distributor. Need support for your Extron FOX R USB Extender Plus HID SM? Ampronix offers professional repair, exchange, and replacement services for this product and the broader Extron FOX line.

Also referenced as Extron FOXRUSBExtenderPlusHIDSM, FOX-R-USB-Extender-Plus-HID-SM, part number 60152622.
