Extron FOX3 I/O 88 MM (part number 70-1107-01) — the multimode 8x8 fiber optic I/O board used to build or expand Extron FOX3 Matrix 40x, 80x, 160x, 320x, 560x, and 840x switchers.

Every FOX3 Matrix frame from the 40x through the 840x is assembled from these individual 8-in by 8-out I/O boards, and this is the multimode version, carrying 8 multimode SFPs behind 16 LC connectors. Integrators add boards to grow a matrix from its base configuration toward its maximum size, or swap one in as a hot-swappable replacement for a failed board, without powering down the frame or interrupting signal routing on the remaining boards.

Key Capabilities

• 8 multimode SFPs per board, 16 LC connectors, hot-swappable
• Up to 500 m (1640 feet) reach on 50 µm OM4 laser-optimized multimode fiber
• Carries 4K/60 4:4:4 video, audio, USB, control, and 3D sync over each fiber link
• 10 Gbps per-channel data rate, HDMI 2.0 and HDCP 2.3 compliant signal path
• Compatible with FOX3 Matrix 40x, 80x, 160x, 320x, 560x, and 840x frames

Where It Is Used

This board is the standard building block for expanding any mid-to-large FOX3 Matrix frame in buildings and campuses where multimode fiber runs already exist, or where run lengths stay under the 500 m multimode limit — broadcast facilities, command centers, and large corporate campuses.

Specifications at a Glance

• Number/type: 8 multimode SFPs per board
• Connectors: 16 LC connectors per board
• Operating distance: 500 m (1640 feet), OM4 multimode fiber
• Nominal wavelength: 850 nm

Also referenced as Extron FOX3IO88MM, FOX3-I-O-88-MM, part number 70110701.
