Extron EWB 102 Two-Gang External Wall Box
- • Extron EWB 102 two-gang wall box, black
- • Surface-mounts a two-gang faceplate, no in-wall box
- • Steel body 4.50 x 4.56 in, six mounting holes
- • Sales, replacement and exchange
- • Part# 60-1162-02 / 60116202
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Extron EWB 102 (part number 60-1162-02) - two-gang external wall box in black, for surface-mounting a two-gang Extron faceplate.
The second gang is what most AV positions actually need. A single outlet covers a display feed; two covers a display feed plus control, or a source input plus network, without splitting the position across two boxes on the wall. This steel enclosure carries a two-gang faceplate on the wall surface, giving 2.50 in of depth for the wiring behind it. Cable can arrive through the surface raceway knockouts on the box or from the wall cavity at the rear, and six mounting holes spread the fixing load across the wider body.
Key Capabilities
- Surface-mounts a two-gang Extron faceplate with no in-wall box
- 2.50 in of internal depth for faceplate wiring
- Two small and two large knockouts for surface raceway channels
- Also accepts cable runs from the rear wall space
- Steel body, 4.50 in H x 4.56 in W, weighing 0.9 lbs
- Six wall mounting holes; c-UL and UL listed
Where It Is Used
Teaching walls and lecture positions, meeting-room source walls, control rooms, and healthcare or laboratory spaces where two AV connections belong at one wall point and the wall itself cannot be opened up.
Specifications at a Glance
- Enclosure: 4.50 in H x 4.56 in W x 2.50 in D (11.4 x 11.6 x 6.4 cm)
- Product weight: 0.9 lbs (0.4 kg); shipping weight 2 lbs
- Material: steel
- Wall mounting holes: 6
- Compliance: c-UL, UL, RoHS, WEEE; 3-year parts and labor warranty
Frequently asked questions about the Extron EWB 102 Two-Gang External Wall Box Black
Does Ampronix sell the Extron EWB 102 Two-Gang External Wall Box Black?
Yes. Ampronix is an authorized Extron distributor and sells the Extron EWB 102 Two-Gang External Wall Box Black (60-1162-02). Call Ampronix for a quote.
Does Ampronix offer replacement and exchange for the Extron EWB 102 Two-Gang External Wall Box Black?
Yes. Ampronix provides sales, replacement and exchange for the Extron EWB 102 Two-Gang External Wall Box Black. Call Ampronix for a quote.
Is the Extron EWB 102 Two-Gang External Wall Box Black listed under other names?
Yes. The Extron EWB 102 Two-Gang External Wall Box Black is also referenced as Extron EWB102, EWB-102, part number 60116202.
What are the key features of the Extron EWB 102 Two-Gang External Wall Box Black?
Key points: Surface-mounts a two-gang Extron faceplate with no in-wall box; 2.50 in of internal depth for faceplate wiring; Two small and two large knockouts for surface raceway channels; Also accepts cable runs from the rear wall space. Call Ampronix to confirm details for your application.
Also referenced as Extron EWB102, EWB-102, part number 60116202.
