Extron EWB 101 (part number 60-452-05) — one-gang external wall box finished in RAL9010 white, a retired Extron order code.

RAL9010 is a specified colour rather than a generic white, which is precisely why this variant existed: European projects and architectural specifications frequently call out a RAL reference, and an approximate match is a defect. Underneath the finish it is the standard EWB single-gang box — steel, surface-mounted, 2.50 in deep, with raceway knockouts and an open rear for cavity cabling. Extron has since retired the code, so it is now a sourcing item rather than a catalogue line.

Key Capabilities

• Finished to RAL9010 white for specification-driven projects
• One-gang external wall box, surface-mounted, no cutting required
• 2.50 in depth to house the faceplate wiring
• Two small and two large surface raceway knockouts
• Steel body, 4.50 in H x 2.75 in W, 0.7 lbs
• Retired Extron order code, sourced on request

Where It Is Used

Architecturally specified interiors, European projects working to RAL colour schedules, and heritage or design-led buildings where the AV hardware has to match a documented finish exactly rather than approximately.

Specifications at a Glance

• Enclosure: 4.50 in H x 2.75 in W x 2.50 in D (11.4 x 7.0 x 6.4 cm)
• Finish: RAL9010 white
• Product weight: 0.7 lbs (0.3 kg)
• Wall mounting holes: 4
• Compliance: c-UL, UL, RoHS, WEEE

Also referenced as Extron EWB101, EWB-101, part number 6045205.
