Extron eLink 100 T EU Wireless HDMI Transmitter
- • Extron eLink 100 T EU wireless HDMI transmitter
- • Up to 1080p/60 over 100 ft (30 m) range
- • AES-128 encrypted 5 GHz link, under 1 ms latency
- • Sales, replacement and exchange
- • Part# 60-1490-12 / 60149012
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Extron eLink 100 T EU (part number 60-1490-12) - wireless HDMI transmitter for the eLink 100 extender set, EU RF band.
The eLink 100 T pairs with up to four eLink 100 R receivers to carry HDMI video and multi-channel audio wirelessly up to 100 ft through walls and furniture in the 5 GHz band. This transmitter accepts a single-link HDMI source, encrypts the feed with AES-128, and actively scans the RF spectrum to keep the link clear of interference from other wireless systems.
Key Capabilities
- Wireless HDMI transmission up to 1080p/60, VESA up to 1920x1080 @ 60 Hz
- AES-128 encrypted 5 GHz link with under 1 ms system latency
- Operates on the EU non-DFS/DFS frequency plan
- One transmitter distributes to up to four eLink 100 R receivers
- Automatic and dynamic frequency selection avoids interference
- Compact 1.4 x 3.2 x 4.0 in enclosure, wall mountable
Where It Is Used
Deployed alongside its eLink 100 R counterpart in boardrooms, classrooms, and portable-lectern setups where running HDMI cable is impractical - historic buildings, divisible rooms, and rental/staging work all benefit from the wireless run.
Specifications at a Glance
- Signal: 1 single-link HDMI/DVI-D input, HDCP 2.0 compliant
- Transmission: up to 100 ft (30 m), 5 GHz MIMO link
- Power: 7.5 W device / 8.8 W with external power supply
- Enclosure: 1.4 x 3.2 x 4.0 in, 0.3 lb
- Warranty: 3 years parts and labor
Frequently asked questions about the Extron eLink 100 T EU Wireless HDMI Transmitter
Does Ampronix sell the Extron eLink 100 T EU Wireless HDMI Transmitter?
Yes. Ampronix is an authorized Extron distributor and sells the Extron eLink 100 T EU Wireless HDMI Transmitter (60-1490-12). Call Ampronix for a quote.
Does Ampronix offer replacement and exchange for the Extron eLink 100 T EU Wireless HDMI Transmitter?
Yes. Ampronix provides sales, replacement and exchange for the Extron eLink 100 T EU Wireless HDMI Transmitter. Call Ampronix for a quote.
Is the Extron eLink 100 T EU Wireless HDMI Transmitter listed under other names?
Yes. The Extron eLink 100 T EU Wireless HDMI Transmitter is also referenced as Extron eLink100TEU, eLink-100-T-EU, part number 60149012.
What are the key features of the Extron eLink 100 T EU Wireless HDMI Transmitter?
Key points: Wireless HDMI transmission up to 1080p/60, VESA up to 1920x1080 @ 60 Hz; AES-128 encrypted 5 GHz link with under 1 ms system latency; Operates on the EU non-DFS/DFS frequency plan; One transmitter distributes to up to four eLink 100 R receivers. Call Ampronix to confirm details for your application.
Also referenced as Extron eLink100TEU, eLink-100-T-EU, part number 60149012.
Related: Extron products, Video Solutions.
