Extron DVI DA8 Plus (part number 60-933-01) — the eight output member of the DVI DA Plus family, a 1U full-rack DVI distribution amplifier with EDID Minder and rack brackets included.

Eight sinks on one DVI source is the point at which passive splitting stops being an option. This amplifier equalizes the incoming run first, compensating for as much as 100 feet of Extron DVI Pro cable at 1920x1200 with 8-bit colour, then retimes and reshapes the stream so that every one of the eight outputs receives a regenerated, low-jitter copy rather than a progressively degraded one. EDID Minder handles the other half of the problem, presenting a consistent EDID to the source so it initialises at the right timing and does not renegotiate when a display is powered down. Each output carries +5 VDC at 250 mA for in-line peripherals.

Key Capabilities

• Eight single link DVI-D outputs on female DVI-I connectors from one female DVI-I input.
• 4.95 Gbps maximum data rate, 1.65 Gbps per colour, on a 165 MHz pixel clock.
• Computer video to 1920x1200 plus HDTV 1080p/60 and 2K.
• Full signal regeneration on all eight outputs, not simple buffering.
• +5 VDC at 250 mA per output for peripheral powering.
• External 12 VDC 2 A 24 W supply on universal 100-240 VAC input.

Where It Is Used

Large control room and NOC display walls, casino and stadium monitoring, hospital departmental display arrays, transport information systems, and any legacy DVI plant where a single source has to be mirrored to eight positions without image variation between them.

Specifications at a Glance

• I/O: 1 female DVI-I in, 8 female DVI-I out
• Rate: 4.95 Gbps maximum, 165 MHz pixel clock
• Power: external 12 VDC 2 A 24 W; unit draws 12 VDC at 1.5 A max
• Enclosure: metal, 1.75" H x 17.5" W x 8.5" D, 1U full rack
• Warranty: 3 years product, 7 years Everlast power supply

Also referenced as Extron DVIDA8Plus, DVI-DA8-Plus, part number 6093301. Extron lists this part number as retired.
