Extron DTP T EU 4K 231 60-1532-12 Junction Box Transmitter
Extron DTP T EU 4K 231 60-1532-12 Junction Box Transmitter
- • Extron DTP T EU 4K 231 junction box transmitter
- • HDMI in to DTP out; 230 ft (70 m) at 1080p/60
- • EU one-gang box; remotely powered over DTP
- • Sales, replacement and exchange
- • Part# 60-1532-12 / 60153212
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Manufacturer: Extron; Model: DTP T EU 4K 231; Part number: 60-1532-12 (also written 60153212)
The Extron DTP T EU 4K 231 (60-1532-12) is a new one-gang EU-type junction box HDMI transmitter available through Ampronix. It accepts an HDMI source and sends video at resolutions up to 4K, plus embedded audio and bidirectional RS-232 and IR, up to 230 ft (70 m) to a DTP-enabled receiver or matrix over shielded CATx. Remote power from the receiver means no mains outlet is needed behind the plate. HDBaseT compatible.
Key capabilities
- EU junction box form factor for one-gang wall installation
- HDMI input to DTP output, video to 4K, 230 ft (70 m) reach
- Powered remotely over the DTP link - no local mains outlet needed
- Bidirectional RS-232 and IR pass-through over the same CATx cable
- HDBaseT-compatible for connection to HDBaseT-enabled displays and switches
Where it is used
European boardrooms, lecture halls, and training rooms where HDMI sources at the wall or table need to connect to a remote DTP matrix or receiver without a surface-mount box.
Specifications at a glance
- Input: 1 HDMI; Output: 1 DTP/HDBaseT over RJ-45
- Reach: 230 ft (70 m) at 1080p/60; 130 ft (40 m) at 4K/30
- Warranty: 3-year product, 7-year Everlast power supply
Frequently asked questions about the Extron DTP T EU 4K 231
Is the Extron DTP T EU 4K 231 60-1532-12 available new or refurbished?
Ampronix stocks the DTP T EU 4K 231 (60-1532-12) as a new unit through its authorized Extron distribution agreement.
Is the DTP T EU 4K 231 compatible with HDBaseT receivers and switchers?
Yes. The 60-1532-12 is HDBaseT compatible, allowing connection to both Extron DTP-enabled devices and third-party HDBaseT receivers and matrix switchers.
Does Ampronix offer replacement and exchange for the Extron DTP T EU 4K 231?
Yes. Ampronix provides sales, replacement and exchange for the DTP T EU 4K 231 and the broader Extron DTP transmitter line.
Ampronix is an authorized Extron distributor. Need a replacement or exchange for your Extron DTP T EU 4K 231? Ampronix provides sales, replacement and exchange for this product and the broader Extron DTP line.
Also referenced as Extron DTPtEU4K231, DTP-T-EU-4K-231, part number 60153212.
Related: Extron products, Video Solutions.
