Extron DTP HDMI 4K 330 Rx HDMI Twisted Pair Receiver
- • Full 330 ft (100 m) reach at every rated format, 4K included
- • Recovers 4K/UHD at 60 Hz using 4:2:0 chroma subsampling
- • 10.2 Gbps data rate, 300 MHz pixel clock, HDCP 2.3
- • HDMI type A output also drives DVI-D with an adapter
- • RS-232 on a 3-pole captive screw plus 30-60 kHz IR
- • 4.2 W device draw, or remote power within 12 W
- • 1.0 lb quarter-rack metal case, convection cooled
- • 3-year warranty; 7 years on the Everlast power supply
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Extron DTP HDMI 4K 330 Rx (part number 60-1331-13) — the long-reach receiver in Extron's DTP HDMI 330 4K family, holding full resolution out to a hundred metres of shielded twisted pair.
What separates the 330 from the shorter 230 version is that the distance figure does not fall away as resolution climbs. Every format Extron rates for this link, from 1080p at 60 Hz through 2560x1600 and on to 4K and UHD at 30 or 60 Hz, is specified to the same 330 feet. That makes cable planning simple: one number covers the whole room. The unit lands the shielded CATx run on a female RJ-45 and presents recovered video on a single female HDMI type A output, with a DVI-D sink supported through a suitable cable or adapter. Its partner transmitter, the DTP HDMI 4K 330 Tx, ships separately.
Key Capabilities
- Holds 330 feet (100 m) at every rated format, including 4K and UHD at 30 Hz and 60 Hz
- Outputs 4096x2160 or 3840x2160, with 60 Hz reached via 4:2:0 chroma subsampling
- 10.2 Gbps maximum data rate, 300 MHz maximum pixel clock, HDCP 2.3 support
- Breaks RS-232 out on a 3.5 mm 3-pole captive screw connector, plus 30 kHz to 60 kHz IR
- Analog stereo output reaches beyond +11 dBu balanced into 600 ohms, with 0.03% THD+N
- Uses 4.2 watts on its own supply, or remote power inside a 12 watt budget
Where It Is Used
Auditoriums and large lecture halls where the projector sits at the back of a long throw, multi-floor corporate buildings running video between a basement rack and an upper-level display, hospital imaging and reading rooms, and command centres where distance rather than resolution dictates the design.
Specifications at a Glance
- Reach: 330 ft (100 m) at 1080p/60, 2560x1600/60 and 4K/UHD alike
- Video output: 1 female HDMI type A, single link HDMI or DVI-D
- Cable: 24 AWG or better solid conductor STP, 400 MHz, TIA/EIA T568B
- Enclosure: metal, 1.0 in H x 4.3 in W x 6.0 in D, quarter rack wide, 1.0 lb (0.5 kg)
- Thermal dissipation: 13.0 BTU/hr device, 18.7 BTU/hr with the power supply
Also referenced as Extron DTPHDMI4K330Rx, DTP-HDMI-4K-330-Rx, part number 60133113.
