Extron DMS Matrix Blank Plate (part number 70-841-01) — a single-slot cover for an unused I/O bay in a DMS 1600 or DMS 3600 frame.

Modular DMS frames rarely ship fully populated — integrators size the board count to the project and leave room to grow. This blank plate closes off any slot that does not yet hold a DVI or fiber I/O board, keeping the chassis airflow path sealed and the front panel finished until a board is added later. It is a passive metal cover with no electronics, so it carries none of the video, control, or power specifications of the boards or frame around it.

Key Capabilities

• Covers one open I/O slot on a DMS 1600 or DMS 3600 frame
• Maintains correct front panel airflow and appearance
• Passive metal plate, no electronics or wiring
• Simple swap-out when a board is added later

Where It Is Used

Any DMS 1600 Frame or DMS 3600 Frame installation that is not populated with a board in every slot, where an open bay needs to be covered rather than left exposed.

Specifications at a Glance

• Compatible with: DMS 1600 Frame, DMS 3600 Frame
• Covers: 1 I/O slot
• Construction: metal
• Warranty: 3 years parts and labor

Also referenced as Extron DMSMatrixBlankPlate, DMS-Matrix-Blank-Plate, part number 7084101.
