Extron CTL/500 (part number 22-148-02) — the 500 ft spool of Extron's non-plenum Comm-Link cable, for control runs that do not need a full 1,000 ft reel.

CTL bundles the two halves of a control drop into one gray jacket. A pair of 18 AWG bare copper conductors handles the power side; a twisted, shielded pair of 22 AWG conductors handles the data side. Buying the shorter reel keeps leftover cable off the job when a project needs one or two rooms wired rather than a whole floor. Keep it out of return-air plenums — this version is not plenum rated.

Key Capabilities

• 500 ft (152.4 m) spool, one of two standard CTL put-ups
• Two 18 AWG power conductors, 19/30 stranding, 0.048 in (1.22 mm), bare copper
• Shielded 22 AWG data pair, 7/30 stranding, 0.030 in (0.76 mm), bare copper
• Aluminum foil shield at 100% coverage backed by a 95% tinned copper serve
• Foamed polyolefin insulation, PVC inner jackets, gray PVC outer jacket
• NEC CM, UL 1581 and CSA FT-4 ratings; 60 °C UL AWM

Where It Is Used

Typical placements are training rooms, huddle spaces, divisible classrooms and small control rooms — anywhere a processor in a rack has to reach a wall plate or button panel across the room and power it at the same time. It also links third-party control heads back to their processors.

Specifications at a Glance

• Length: 500 ft (152.4 m) spool
• Rating: Non-plenum
• Nominal OD: 0.220 in (5.59 mm)
• Shield DCR: 12.2 ohms/1,000 ft (40.0 ohms/km)
• Shipping weight: 21 lbs (9.5 kg)

Also referenced as Extron CTL500, CTL-500, part number 2214802.
