Extron CA 83T LP Column Array Speaker
- • White RAL 9003 finish across chassis, endcaps and grille
- • Two-piece low-profile mount, +/- 5 deg tilt, 1.2 lbs (0.5 kg)
- • 90 dB SPL nominal sensitivity, 1 W at 1 m, 6.5 ohms direct
- • 120 W rms continuous pink noise, 240 W rms continuous program
- • Rotary tap selector for 70 V, 100 V or direct operation
- • IP54 rated aluminum enclosure, 29.8 in. tall
- • 5 years parts and labor warranty
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Extron CA 83T LP (part number 42-357-03) — white eight-driver column array loudspeaker with the low-profile wall mounting system included.
This part pairs the shallow SMK LP CA bracket with a white finish, the combination architects usually ask for when a speaker has to be present but not visible. Acoustically it is the standard CA 83T: eight 3 in. (76 mm) drivers over 29.8 in. of aluminum extrusion, 109 dB maximum SPL, and a vertical pattern that narrows steadily with frequency so reflective ceilings receive far less energy than a conventional box would send them.
Key Capabilities
- White RAL 9003 finish across chassis, endcaps and grille
- Two-piece low-profile mount with +/- 5° tilt, weighing 1.2 lbs (0.5 kg)
- 90 dB SPL nominal sensitivity, 1 W at 1 m, 6.5 ohms direct
- 120 W rms continuous pink noise, 240 W rms continuous program
- Rotary tap selector on the underside for 70 V, 100 V or direct operation
- IP54 rated aluminum enclosure
Where It Is Used
Museums, chapels, seminar rooms, council chambers and raked teaching spaces with light finishes are the usual homes. As a fill speaker it also pairs with CA 163 columns on a front wall, since Extron voices every CA Series model consistently and the visual language matches.
Specifications at a Glance
- Frequency range 113 Hz to 17.1 kHz, -10 dB, full space
- Coverage 180° H x 38° V at 1 kHz, measured at 4 m
- Enclosure 29.8 in. H x 5.0 in. D x 4.5 in. W, 16.9 lbs (7.7 kg)
- Operating range +32 to +122°F (0 to +50°C), 10% to 90% noncondensing
- 5 years parts and labor warranty
Also referenced as Extron CA83TLP, CA-83T-LP, part number 4235703.
