Extron CA 83T LP Column Array Speaker
- • Low-profile bracket with +/- 5 deg vertical tilt, included
- • Eight 3 in. drivers handling 240 W rms continuous program
- • 70 V taps at 64/32/16/8 W and 100 V taps at 64/32/16 W
- • 109 dB maximum SPL at 1 m, full space
- • IP54 ingress protection on the aluminum enclosure
- • Black RAL 9011 chassis with RAL 9017 endcaps and grille
- • 5 years parts and labor warranty
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Extron CA 83T LP (part number 42-357-02) — black eight-driver column array loudspeaker supplied with the two-piece low-profile SMK LP CA wall mount.
The LP variant is for rooms where the array needs to sit close to the wall and only a few degrees of downward aim are required, typically because the seating is already raked. Eight 3 in. (76 mm) paper cone drivers occupy a 29.8 in. extruded aluminum column rated at 240 W rms continuous program. A rotary selector under the enclosure chooses between 70 V taps, 100 V taps and 6.5 ohm direct connection, and the IP54 rating means dust and splashes are not an immediate problem.
Key Capabilities
- Low-profile bracket with +/- 5° of vertical tilt, included with the speaker
- Eight 3 in. (76 mm) drivers handling 240 W rms continuous program
- 70 V taps at 64/32/16/8 W and 100 V taps at 64/32/16 W
- 109 dB maximum SPL at 1 m, full space
- IP54 ingress protection
- Black RAL 9011 chassis with RAL 9017 endcaps and grille
Where It Is Used
Tiered classrooms, small raked auditoriums, worship spaces with sloped floors and briefing rooms suit the shallow bracket. Because the mount adds only 1.2 lbs (0.5 kg) and very little depth, it also works where a facilities standard limits how far equipment may project from a finished wall.
Specifications at a Glance
- Frequency response 220 Hz to 15.5 kHz, -3 dB, full space
- Coverage 180° H x 73° V at 500 Hz and 180° H x 9.5° V at 4 kHz
- Enclosure 29.8 in. H x 5.0 in. D x 4.5 in. W (757 x 127 x 114 mm)
- Speaker weight 16.9 lbs (7.7 kg); nominal impedance 6.5 ohms
- 5 years parts and labor warranty
Also referenced as Extron CA83TLP, CA-83T-LP, part number 4235702.
