Extron CA 43T LP (part number 42-360-02) — black four-driver column array loudspeaker with the two-piece SMK LP CA low-profile wall mount included.

The low-profile kit holds the column less than an inch off the wall surface and allows up to five degrees of tilt in either direction, set by adding an extension knob to the top or bottom knurled knob. That makes it the right choice where the audience already sits below the speaker axis or where the finished wall cannot carry a projecting bracket. Acoustically this is the standard CA 43T: four 3 in. (76 mm) full-range drivers, 120 watts of continuous program, and a rotary tap selector on the base for 6.5 ohm, 70 V or 100 V operation.

Key Capabilities

• Sits less than 1 in. (25 mm) off the wall, with +/- 5° of tilt
• Four matched 3 in. (76 mm) drivers, 60 W pink noise and 120 W program
• 70 V taps at 32/16/8/4 W and 100 V taps at 32/16/8 W
• 6.5 ohm direct mode on the same rotary selector
• IP54 protection against dust and water spray
• Black RAL 9011 chassis with RAL 9017 endcaps and grille

Where It Is Used

Tiered classrooms, small raked lecture rooms, corridors, lobbies and meeting rooms with shallow wall reveals all suit this configuration. Extron ships a dual-sided mounting template with the speaker, so a single installer can position, level and secure the brackets without a second pair of hands.

Specifications at a Glance

• Frequency range 125 Hz to 17.1 kHz, -10 dB, full space
• Coverage 180° H x 72° V at 1 kHz, measured at 4 m
• Enclosure 16.93 in. H x 5.0 in. D x 4.5 in. W (430 x 127 x 114 mm)
• SMK LP CA mount weighs 1.2 lbs (0.5 kg)
• 5 year parts and labor warranty

Also referenced as Extron CA43TLP, CA-43T-LP, part number 4236002.
