Extron CA 163 PT Column Array Speaker
- • White 70/100 V column array for constant voltage distributed systems
- • 91 dB max SPL at 70 V and 94 dB at 100 V, measured at 1 m
- • 83 dB SPL nominal sensitivity, 1 W at 1 m, 50 ohms direct
- • Sixteen 3 in. paper cone drivers in a 51.9 in. aluminum column
- • Coverage of 180 deg H x 20 deg V at 1 kHz, measured at 4 m
- • Transformerless build preserves tonality across mixed systems
- • 5 year Extron parts and labor warranty
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Extron CA 163 PT (part number 42-338-13) — white long throw column array loudspeaker for 70/100 volt distributed systems, supplied with the SMK PT CA pan and tilt wall mount.
This is the high impedance member of the CA 163 family in a white powder coat, intended for constant voltage lines. Because Extron builds the high impedance version without a transformer, high pass filtering is unnecessary and the speaker keeps the same tonal signature as its 8 ohm sibling. The enclosure holds sixteen 3 in. (76 mm) paper cone drivers over 51.9 in. of height, producing a wide horizontal pattern with tight vertical control that keeps reflected energy off hard ceilings and floors.
Key Capabilities
- 70 V and 100 V operation, 50 ohm nominal impedance, no transformer
- 91 dB maximum SPL at 70 V and 94 dB at 100 V, measured at 1 m full space
- 240 W rms continuous pink noise, 480 W rms continuous program
- Nominal coverage 180° H x 20° V at 1 kHz, 155° H x 14° V at 2 kHz
- White RAL 9003 powder coat across chassis, endcaps and grille
- Pan and tilt wall mount rated for one-person installation
Where It Is Used
White column arrays blend into light-coloured walls in chapels, museums, airport concourses, lecture theatres and civic halls. On a 70/100 V backbone a single amplifier channel can feed several of these speakers, which makes the version practical for long side walls and rear fill in large reverberant rooms.
Specifications at a Glance
- Sixteen 3 in. (76 mm) paper cone drivers; 83 dB SPL sensitivity at 1 W, 1 m
- Frequency response 200 Hz to 16 kHz, -3 dB, full space
- Enclosure 51.9 in. H x 5.0 in. D x 4.5 in. W (1318 x 127 x 114 mm)
- Operating range +32 to +122°F (0 to +50°C), 10% to 90% noncondensing
- 5 year parts and labor warranty
Also referenced as Extron CA163PT, CA-163-PT, part number 4233813.
