Extron CA 163 LP Column Array Speaker
- • 70 V and 100 V line operation at 50 ohms nominal impedance
- • Transformerless design removes the need for high pass filtering
- • 91 dB max SPL at 70 V and 94 dB at 100 V, 1 m full space
- • Sixteen 3 in. drivers rated 480 W rms continuous program
- • Low-profile mount adds 1.2 lbs (0.5 kg) and +/- 5 deg of tilt
- • Black RAL 9011 chassis with RAL 9017 endcaps and grille
- • 5 year Extron parts and labor warranty
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Extron CA 163 LP (part number 42-339-12) — black 70/100 volt long throw column array loudspeaker with the low-profile SMK LP CA wall mount.
On a constant voltage backbone one amplifier channel can feed a run of speakers, which is why large venues standardise on 70 V or 100 V distribution. Extron builds the high impedance CA 163 without a transformer, so high pass filtering is not required and the speaker keeps the same voicing as the 8 ohm version used elsewhere in the same room. Sixteen 3 in. (76 mm) drivers fill a 51.9 in. aluminum column; part 42-339-12 is the black, single-speaker configuration with the shallow bracket.
Key Capabilities
- 70 V and 100 V line operation, 50 ohm nominal impedance
- No transformer, so no high pass filter is needed in the signal path
- 91 dB maximum SPL at 70 V and 94 dB at 100 V, 1 m full space
- 240 W rms continuous pink noise, 480 W rms continuous program
- Low-profile mount adds only 1.2 lbs (0.5 kg) and +/- 5° of tilt
- Black RAL 9011 chassis with RAL 9017 endcaps and grille
Where It Is Used
Distributed systems in convention centers, sports venues, transport terminals, worship spaces and large lecture theatres rely on constant voltage lines. This version drops into side wall and rear fill positions in raked rooms, complementing low impedance CA 163 units already carrying the front-of-room load.
Specifications at a Glance
- 83 dB SPL nominal sensitivity, 1 W at 1 m, 50 ohms direct
- Frequency range 105 Hz to 20 kHz, -10 dB, full space
- Coverage 155° H x 14° V at 2 kHz, measured at 4 m
- Enclosure 51.9 in. H x 5.0 in. D x 4.5 in. W, 27.6 lbs (12.5 kg)
- 5 year parts and labor warranty
Also referenced as Extron CA163LP, CA-163-LP, part number 4233912.
