Extron BCK SF 26CT Speaker Back Can
- • Plenum-rated back can pair for the Extron SF 26CT two-way ceiling speaker
- • Composite fire-resistant enclosure measuring 8.34 inch H x 10.64 inch diameter
- • 9.3 inch cutout with locking arms for ceiling tiles up to 2.25 inch thick
- • UL 2043 listed for plenum airspace use, UL 1480 listed for pro audio
- • Ships with cutout template, mounting screws, V-rails, C-rings, and connectors
- • Pairs with the DAK SF 26CT driver assembly kit to complete the speaker
Product discontinued.
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Extron BCK SF 26CT (part number 70-1268-01) — plenum-rated back can pair for the SF 26CT two-way ceiling speaker, sold without the driver assembly.
The BCK SF 26CT is the enclosure half of the SF 26CT speaker system: a fire-resistant composite back can that mounts in the ceiling grid and accepts the separately ordered DAK SF 26CT driver assembly kit to become a complete, plenum-rated two-way speaker. Ordering the back can on its own suits modular jobs — rough-in before drivers ship, replacement of a damaged can, or projects that stage enclosure and driver installation separately.
Key Capabilities
- Plenum-rated back can pair for the Extron SF 26CT two-way ceiling speaker
- Composite fire-resistant (UL94V-0) enclosure measuring 8.34" H x 10.64" diameter
- Cutout diameter of 9.3" with locking arms for ceiling tiles up to 2.25" thick
- UL 2043 listed for plenum airspace use, UL 1480 listed for pro audio systems
- Ships with cutout template, mounting screws, 4 V-rails, 2 C-rings, and captive screw connectors
- Pairs with the DAK SF 26CT driver assembly kit to complete the full SF 26CT speaker
Where It Is Used
Used on SF 26CT installations in conference rooms, classrooms, auditoriums, and houses of worship where the back can and driver kit are procured or installed as separate phases of a plenum ceiling speaker rollout.
Specifications at a Glance
- Enclosure: Plenum-rated composite back can, UL94V-0
- Cutout: 9.3" diameter
- Ceiling thickness: Up to 2.25"
- Pairs with: DAK SF 26CT driver assembly kit
Also referenced as ExtronBCKSF26CT, Extron-BCK-SF-26CT, part number 70126801.
