Extron AC USB AAP (part number 70-608-03) — the white finish of Extron's AAP AV connectivity module combining a US AC outlet with a USB pass-through.

Extron's model table lists this part as the white version of the AC USB AAP, matching the black 70-608-02. The white finish matters when the plate has to disappear into pale millwork, a light lectern or a white wall rather than a dark equipment surface. Functionally it is identical: a double-space AAP plate that brings a mains socket and a USB connection to the working surface. The AC outlet carries 125 VAC, 50-60 Hz at up to 12 A through a 9 ft (2.7 m) cord fitted with a NEMA 5-15R receptacle at the plate and a NEMA 5-15P plug at the wall end.

Key Capabilities

• White double-space AAP plate with AC outlet and USB pass-through
• 125 VAC, 50-60 Hz outlet rated to 12 A maximum
• 9 ft (2.7 m) AC cord, NEMA 5-15R to NEMA 5-15P
• Faceplate measures 1.39 x 3.50 in (35 x 89 mm)
• Needs at least 2.77 in (70 mm) of depth behind the surface
• Rack or furniture mountable with optional AAP frames
• Metal enclosure, UL, c-UL and CE compliant

Where It Is Used

Chosen for light-coloured lecterns and casework, classroom and lecture-theatre furniture, healthcare and laboratory rooms with white finishes, and hospitality millwork, wherever the plate should blend into the surface instead of standing out against it.

Specifications at a Glance

• Finish: white
• Power: 125 VAC, 50-60 Hz, 12 A max
• Faceplate: 1.39 x 3.50 in (35 x 89 mm), double space AAP
• Mounting: rack or furniture, optional AAP frames
• Warranty: 3 years parts and labor

Extron's model table does not state the USB revision for 70-608-03, and lists the part as retired. Confirm the USB version and availability with Ampronix before ordering.

Also referenced as Extron ACUSBAAP, AC-USB-AAP, part number 7060803.
