Extron AC Net AAP FRANCE - Black (part number 70-571-02) — a triple-space AAP connectivity module built for French mains.

This module places one unswitched AC receptacle rated for 220-240 V, 50-60 Hz at up to 6 A alongside an RJ-45 female-to-female CAT5e barrel inside a single black AAP faceplate. Integrators drop the metal assembly into a standard AAP mounting frame so one plate opening delivers both mains power and a network pass-through, cutting the need for a second wall or furniture cutout. Extron has retired part number 70-571-02, so Ampronix stock is genuine remaining inventory rather than current production.

Key Capabilities

• 220-240V unswitched AC outlet rated up to 6 A for France mains
• RJ-45 female-to-female CAT5e barrel for a same-plate network pass-through
• Triple-space AAP faceplate measuring 2.1 in H x 3.5 in W
• Metal isolation enclosure sized 1.9 in H x 1.8 in W x 3.0 in D
• Drops into any standard optional AAP mounting frame
• Covered by Extron's 3-year parts and labor warranty

Where It Is Used

Integrators specify this black France module for lecterns, credenzas and wall AAP plates in boardrooms, classrooms and huddle spaces in France, wherever a single cutout needs to supply both device power and a data jack for a table-mounted laptop or interface.

Specifications at a Glance

• Power: 220-240 VAC, 50-60 Hz, 6 A max.
• Faceplate: 2.1 in H x 3.5 in W, three-space AAP plate
• Enclosure: Metal, 1.9 in H x 1.8 in W x 3.0 in D
• Weight: 0.5 lb (0.2 kg)

Also referenced as Extron ACNetAAP7057102, AC-Net-AAP-70-571-02, part number 7057102.
