Extron AC Net AAP 70-570-02 Israel Black
- • Israel black triple-space AAP module: one unswitched AC outlet plus RJ-45 barrel
- • 220-240 VAC, 50-60 Hz, 6 A maximum load for Israeli installations
- • Triple-space AAP fits standard Extron AAP mounting frames
- • Metal isolation enclosure: 1.9 in H x 1.8 in W x 3.0 in D
- • CE, RoHS and WEEE compliant. 3-year Extron warranty
Product discontinued.
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Part number 70-570-02 — ISRAEL - Black
The 70-570-02 places one unswitched AC outlet rated for Israel voltages together with an RJ-45 female-to-female barrel inside a black triple-space AAP module. Integrators insert the metal assembly into standard mounting frames so that a single plate opening supplies mains power and a network pass-through, removing the need for separate distribution boxes or additional wall cutouts.
This version operates on 220-240 V at 50-60 Hz with 6 A maximum load. The attached AC cord extends 9 ft with 0.29 in outer diameter. The unit occupies three AAP spaces and requires at least 2.77 in depth clearance behind the faceplate once mounted.
