Extron AC Net AAP 70-569-02 UK Black
- • UK black triple-space AAP module: one unswitched AC outlet plus RJ-45 barrel
- • 220-240 VAC, 50-60 Hz, 6 A maximum load for UK installations
- • Triple-space AAP fits standard Extron AAP mounting frames
- • Metal isolation enclosure: 1.9 in H x 1.8 in W x 3.0 in D
- • CE, RoHS and WEEE compliant. 3-year Extron warranty
Product discontinued.
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Part number 70-569-02 — UK - Black
The 70-569-02 consists of a black triple-space AAP module that houses one unswitched AC receptacle together with an RJ-45 female-to-female barrel. Integrators place the metal unit inside standard mounting frames so that a single plate opening supplies mains power and a network pass-through, removing the need for separate distribution boxes.
This UK version operates at 220-240 VAC, 50-60 Hz, with a 6 A maximum rating. The isolation enclosure measures 1.9 in H x 1.8 in W x 3.0 in D while the faceplate measures 1.39 in H x 3.50 in W. It mounts into optional AAP frames and carries a 9 ft power cord on US models only; choose this part when the installation requires the UK outlet type in black rather than multi-region or US configurations.
