Extron AC Net AAP 70-568-05 EU RAL9010 White
- • Extron AC Net AAP 70-568-05 EU outlet module
- • 220-240 VAC, 50-60 Hz, 6 A maximum load
- • Triple-space AAP, unswitched outlet plus RJ-45
- • Sales, replacement and exchange
- • Part# 70-568-05 / 7056805
Product discontinued.
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Manufacturer: Extron; Model: AC Net AAP EU (RAL9010 White); Part number: 70-568-05 (also written 7056805)
The Extron AC Net AAP EU RAL9010 White (70-568-05) is a new triple-space AAP connectivity module available through Ampronix for European mains installations in RAL9010 white finish. One unswitched 220-240 V AC outlet (50-60 Hz, 6 A max) and an RJ-45 female-to-female barrel. Metal isolation enclosure: 1.9 in H x 1.8 in W x 3.0 in D. Faceplate: 1.39 in H x 3.50 in W. Fits optional AAP frames.
Key capabilities
- One unswitched EU AC outlet: 220-240 V, 50-60 Hz, 6 A max
- RJ-45 female-to-female barrel for network pass-through
- Triple-space AAP, RAL9010 white finish; metal isolation enclosure
- Fits optional AAP frames; CE, RoHS, WEEE compliant
Where it is used
European specification-driven fitouts where RAL9010 white is called out across the room and EU mains power with a network drop is required at the same AAP opening.
Specifications at a glance
- AC: 220-240 V, 50-60 Hz, 6 A max; faceplate: triple-space AAP; finish: RAL9010 white
- Warranty: 3-year Extron parts and labor
Frequently asked questions about the Extron AC Net AAP
Is the Extron AC Net AAP EU RAL9010 White 70-568-05 available new or refurbished?
Ampronix stocks the 70-568-05 as a new unit through its authorized Extron distribution agreement.
What is the difference between RAL9010 white (70-568-05) and standard white (70-568-03)?
RAL9010 is a specific shade of white; for color-critical EU installations where other plates are specified in RAL9010, the 70-568-05 ensures a precise color match that the standard white 70-568-03 may not provide.
Does Ampronix offer replacement and exchange for Extron AC Net AAP modules?
Ampronix supplies a full range of Extron AC Net AAP modules and AC+USB power accessories.
Ampronix is an authorized Extron distributor and carries a full range of Extron AC Net AAP and power connectivity modules.
Also referenced as Extron ACNetAAP EU RAL9010, AC-Net-AAP-70-568-05, part number 7056805.
