Extron AC Net AAP 70-568-03 EU White
- • Extron AC Net AAP 70-568-03 EU outlet module
- • 220-240 VAC, 50-60 Hz, 6 A maximum load
- • Triple-space AAP, unswitched outlet plus RJ-45
- • Sales, replacement and exchange
- • Part# 70-568-03 / 7056803
Product discontinued.
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Manufacturer: Extron; Model: AC Net AAP EU (White); Part number: 70-568-03 (also written 7056803)
The Extron AC Net AAP EU White (70-568-03) is a new triple-space AAP connectivity module available through Ampronix for European mains installations in white finish. One unswitched 220-240 V AC outlet (50-60 Hz, 6 A max) and an RJ-45 female-to-female barrel in a white faceplate. Fits optional AAP frames. Metal isolation enclosure: 1.9 in H x 1.8 in W x 3.0 in D. Faceplate: 1.39 in H x 3.50 in W. CE, RoHS, WEEE compliant.
Key capabilities
- One unswitched EU AC outlet: 220-240 V, 50-60 Hz, 6 A max
- RJ-45 female-to-female barrel for network pass-through
- Triple-space AAP, white finish; metal isolation enclosure
- Fits optional AAP frames; CE, RoHS, WEEE compliant
Where it is used
European conference tables, lecterns, and huddle spaces with light-finish hardware where a single AAP opening must supply both EU mains power and a network drop.
Specifications at a glance
- AC: 220-240 V, 50-60 Hz, 6 A max; faceplate: triple-space AAP; finish: white
- Warranty: 3-year Extron parts and labor
Frequently asked questions about the Extron AC Net AAP
Is the Extron AC Net AAP EU White 70-568-03 available new or refurbished?
Ampronix stocks the 70-568-03 as a new unit through its authorized Extron distribution agreement.
What is the difference between the white 70-568-03 and the black 70-568-02?
Both are functionally identical EU AC Net AAP triple-space modules; the 70-568-03 has a white plate and the 70-568-02 has a black plate.
Does Ampronix offer replacement and exchange for Extron AC Net AAP modules?
Ampronix supplies a full range of Extron AC Net AAP modules and AC+USB power accessories.
Ampronix is an authorized Extron distributor and carries a full range of Extron AC Net AAP and power connectivity modules.
Also referenced as Extron ACNetAAP EU White, AC-Net-AAP-70-568-03, part number 7056803.
