Extron AC Net AAP (part number 70-150-03) — the white US version of Extron's combined AC outlet and RJ-45 AAP connectivity module. Extron lists this part as retired.

Functionally this is the standard US AC Net AAP; what sets 70-150-03 apart is the white faceplate, chosen when the module has to disappear into a pale laminate table or a light lectern rather than stand out. The plate occupies two AAP spaces at 1.39 by 3.50 inches, and behind it sits a metal enclosure with a nine-foot mains cord and a straight-through CAT 5e barrel.

Key Capabilities

• One unswitched AC receptacle, 125 VAC, 50-60 Hz, 12 A maximum
• RJ-45 CAT 5e female-to-female barrel providing a network connection point
• White double-space AAP faceplate, 1.39" H x 3.50" W
• Nine-foot (2.74 m) cord with NEMA 5-15 P to NEMA 5-15 R terminations
• Metal enclosure suited to Extron's optional AAP mounting frames
• 1.1 lb (0.50 kg); c-UL and UL listed; 3 years parts and labor

Where It Is Used

Light-finish conference tables, training-room desks and reception lecterns where black hardware would read as a blemish. Plan for at least 2.77 inches of depth behind the faceplate, and install only into UL-listed furniture products that accept AAP or MAAP modules, or a UL-listed junction box.

Specifications at a Glance

• Power: 125 VAC, 50-60 Hz, 12 A max
• Faceplate: 1.39" H x 3.50" W, double-space AAP, white
• Weight: 1.1 lb (0.50 kg)
• Extron status: Retired

Also referenced as Extron ACNetAAP, AC-Net-AAP, part number 7015003.
