Extron 232/2 9-pin D Male to Female RS-232 Cable
- • Extron 232/2 9-pin D male to female RS-232 cable 2 ft
- • All nine pins wired straight through
- • Pin 2 transmit, 3 receive, 5 ground; NEC CM jacket
- • Sales, replacement and exchange
- • Part# 26-433-01 / 2643301
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Extron 232/2 (part number 26-433-01) - a 2 ft (60 cm) 9-pin D male-to-female RS-232 control cable from the Extron 232 Series.
Two feet is a rack jumper, and that is exactly the job this cable was cut for. Most Extron hardware accepts RS-232, which is how a MediaLink Controller, an IP Link serial interface or a third-party control processor issues commands and reads status back. The 232/2 makes that link between two devices sitting in the same rack without leaving a loop of excess cable behind the rails. All nine pins run straight through, so nothing in the handshake gets dropped: pin 2 carries transmit, pin 3 carries receive, pin 5 is ground, and the remaining pins pass end to end. The jacket is NEC CM rated non-plenum.
Key Capabilities
- 2 ft (60 cm) finished length, measured neck to neck between the strain reliefs.
- 9-pin D male on one end, 9-pin D female on the other.
- All nine pins passed straight through, pin 1 to pin 1 through pin 9 to pin 9.
- Pin 2 transmit, pin 3 receive, pin 5 ground per Extron's cable guide.
- Color-coded conductors from brown on pin 1 through black on pin 9.
- NEC CM rated non-plenum jacket.
Where It Is Used
Inside a single equipment rack: control processor to matrix switcher, scaler to touchpanel interface, DSP to room controller. It is the short serial tail that lives behind a rack shelf in a boardroom, classroom, broadcast suite, operating room video rack or command-center console.
Specifications at a Glance
- Length: 2 ft (60 cm)
- Connectors: 9-pin D male to 9-pin D female
- Pin configuration: all pins passed; Tx on 2, Rx on 3, Gnd on 5
- Jacket rating: NEC CM, non-plenum
Also referenced as Extron 2322, 232-2, part number 2643301.
Frequently asked questions about the Extron 232/2 9-pin D Male to Female RS-232 Cable 2 ft
Does Ampronix sell the Extron 232/2 9-pin D Male to Female RS-232 Cable 2 ft?
Yes. Ampronix is an authorized Extron distributor and sells the Extron 232/2 9-pin D Male to Female RS-232 Cable 2 ft (26-433-01). Call Ampronix for a quote.
Does Ampronix offer replacement and exchange for the Extron 232/2 9-pin D Male to Female RS-232 Cable 2 ft?
Yes. Ampronix provides sales, replacement and exchange for the Extron 232/2 9-pin D Male to Female RS-232 Cable 2 ft. Call Ampronix for a quote.
What are the key features of the Extron 232/2 9-pin D Male to Female RS-232 Cable 2 ft?
Key points: 2 ft (60 cm) finished length, measured neck to neck between the strain reliefs; 9-pin D male on one end, 9-pin D female on the other; All nine pins passed straight through, pin 1 to pin 1 through pin 9 to pin 9; Pin 2 transmit, pin 3 receive, pin 5 ground per Extron's cable guide. Call Ampronix to confirm details for your application.
