Elo 1541L 15.6" WXGA Open-Frame Touchmonitor Display
Elo 1541L 15.6" WXGA Open-Frame Touchmonitor Display
Elo 1541L 15.6" Open-Frame Touchmonitor
- • Elo 1541L | 15.6 in | 1366 x 768
- • IntelliTouch Plus | AccuTouch | USB
- • 500:1 | 250 nit LED Panel
- • VGA + DVI-D Video Inputs
- • 75 mm VESA | Rear Mount
- • Refurbished | E606625 | Free Evaluation
This product has been discontinued by the manufacturer. Contact us for replacement options.
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Manufacturer: Elo | Model: 1541L | Part number: E606625 (IntelliTouch Plus, USB), E805638 (AccuTouch, USB)
The Elo 1541L is a 15.6 inch, 16:9 open-frame LCD touchmonitor with LED backlighting, a native 1366 x 768 resolution and a choice of IntelliTouch Plus surface acoustic wave or AccuTouch 5-wire resistive touch. Ampronix supplies the Elo 1541L as a refurbished unit for gaming, kiosk and self-service integration needs, with sales, service, repair and exchange replacement.
Key capabilities
- 15.6 inch active matrix TFT LCD with LED backlight and a 344.2 x 193.5 mm active area.
- 1366 x 768 native resolution with 500:1 typical contrast and 16 ms typical response time.
- 250 nit LCD panel brightness, 225 nits with IntelliTouch Plus and 200 nits with AccuTouch.
- Choice of IntelliTouch Plus (multi-touch surface acoustic wave) or AccuTouch 5-wire resistive touch, both over USB.
- Injection-molded bezel with a water-resistant 0.5 mm seal, 45.7 mm profile.
- Analog VGA and DVI-D inputs, optional 12 VDC power brick, 75 mm VESA and rear-mount options.
Where it is used
The Elo 1541L is built for gaming machines, kiosks, point-of-information and self-service stations where a compact wide-screen 15.6 inch touchscreen is mounted behind a panel. The 1541L also serves as a replacement for a failed 1541L in an existing enclosure.
Specifications at a glance
- Model 1541L, part numbers E606625 and E805638
- 15.6 inch, 1366 x 768, 16:9, 500:1 contrast
- VGA and DVI-D inputs, USB touch (IntelliTouch Plus or AccuTouch)
- 12 VDC input, power brick sold separately, 15 W typical
- 376.8 x 221.1 x 45.7 mm, 2.9 kg (6.4 lb) unpackaged
Frequently asked questions
Is the Elo 1541L available refurbished?
Yes. Ampronix supplies the Elo 1541L as a refurbished unit, subject to availability. Call Ampronix for current stock and pricing.
Which touch technologies does the Elo 1541L use?
Elo lists two versions: E606625 with IntelliTouch Plus surface acoustic wave (clear surface) and E805638 with AccuTouch 5-wire resistive (anti-glare surface), both with a USB interface.
Does the Elo 1541L include a power supply?
No. The Elo 1541L runs from a 12 VDC input and Elo sold the AC power brick separately. Call Ampronix to confirm the right power brick for your unit.
Which Elo 1541L part numbers does Ampronix cross-reference?
Elo's datasheet lists E606625 (IntelliTouch Plus, USB, clear) and E805638 (AccuTouch, USB, anti-glare). Call Ampronix with your label to confirm the exact match.
Does Ampronix repair and exchange the Elo 1541L?
Yes. Ampronix offers sales, service, repair and exchange replacement for the Elo 1541L. Call Ampronix for a free evaluation and quote.
Ampronix supplies the Elo 1541L and offers professional sales, service, repair, and exchange replacement solutions for this product and the broader Elo touchmonitor line.
Also referenced as: Elo1541L, Elo-1541L, Elo 1541L open frame, 15.6-inch open frame touchmonitor, part numbers E606625, E805638.
Related: Elo products, Touch Screen Display Monitors.
