Elo 1247L 12" SVGA Open-Frame Touchmonitor Display
Elo 1247L 12" SVGA Open-Frame Touchmonitor Display
Elo 1247L 12" Open-Frame Touchmonitor
- • Elo 1247L | 12 in | 800 x 600
- • IntelliTouch | Serial + USB Touch
- • 800:1 | 450 nit Panel
- • VGA Video Input | 12 VDC
- • 75 mm VESA | Rear Mount
- • Refurbished | E655204 | Free Evaluation
This product has been discontinued by the manufacturer. Contact us for replacement options.
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Manufacturer: Elo | Model: 1247L | Part number: E655204 (IntelliTouch, serial/USB, antiglare, worldwide)
The Elo 1247L is a 12.1 inch, 4:3 open-frame LCD touchmonitor with a native 800 x 600 resolution and Elo IntelliTouch surface acoustic wave touch over a dual serial and USB interface. Ampronix supplies the Elo 1247L as a refurbished unit for kiosk, gaming and light industrial integration needs, with sales, service, repair and exchange replacement.
Key capabilities
- 12.1 inch active matrix TFT LCD with a 246 x 185 mm active area.
- 800 x 600 native resolution with 800:1 typical contrast and 25 ms typical response time.
- 450 nit LCD panel brightness, 405 nits typical with IntelliTouch.
- Elo IntelliTouch pure-glass surface acoustic wave touch with dual serial and USB interfaces.
- Integrated precision mini-bezel with a watertight 0.5 mm seal against dirt, dust and liquids.
- Analog VGA input with a 12 VDC external power brick and 75 mm VESA or rear mounting.
Where it is used
The Elo 1247L is built for kiosks, point-of-information displays, gaming systems and industrial automation where a compact 12 inch touchscreen is mounted behind a panel. The 1247L also serves as a replacement for a failed 1247L in an existing enclosure.
Specifications at a glance
- Model 1247L, part number E655204
- 12.1 inch, 800 x 600, 4:3, 800:1 contrast
- Analog VGA input, IntelliTouch with serial and USB
- 12 VDC external power brick, 12 W typical
- 303 x 242 x 60 mm, 4 kg (8.8 lb) unpackaged
Frequently asked questions
Is the Elo 1247L available refurbished?
Yes. Ampronix supplies the Elo 1247L as a refurbished unit, subject to availability. Call Ampronix for current stock and pricing.
Does the Elo 1247L include a power supply?
The Elo 1247L runs from a 12 VDC external power brick (100 to 240 VAC input). Call Ampronix to confirm the right power supply for your unit.
Which touch technology does the Elo 1247L use?
Elo's datasheet lists IntelliTouch surface acoustic wave with a serial and USB interface and an antiglare surface (part number E655204).
What is the maximum resolution of the Elo 1247L?
The native resolution is 800 x 600 at 60 Hz, a 4:3 SVGA panel. Lower resolutions down to 640 x 350 are supported.
Does Ampronix repair and exchange the Elo 1247L?
Yes. Ampronix offers sales, service, repair and exchange replacement for the Elo 1247L. Call Ampronix for a free evaluation and quote.
Ampronix supplies the Elo 1247L and offers professional sales, service, repair, and exchange replacement solutions for this product and the broader Elo touchmonitor line.
Also referenced as: Elo1247L, Elo-1247L, Elo 1247L open frame, 12-inch open frame touchmonitor, part number E655204.
Related: Elo products, Touch Screen Display Monitors.
