The Eizo RadiForce TDL3600-DL is a high-performance Dual Link DVI transmission link designed to extend high-quality video signals between a PC and a monitor over distances of up to 36 meters. Unlike conventional connection cables that limit error-free transmission to a maximum of 5 meters, this robust extender ensures zero loss in image quality, making it an ideal solution for routing medical image signals to ceiling-mounted monitors or remote workstations.

Featuring a compact and lightweight design, the TDL3600-DL consists of a transmitter module on the PC side and a receiver module on the monitor side connected via a standard RJ45 cable. It supports a maximum resolution of 2560 x 1600 (WQXGA) over a Dual Link DVI-D interface. The system is powered directly through the DVI interface on the PC side and via the monitor on the receiver side, with an option for an external 5V power supply if required.

Built to meet the rigorous demands of medical environments, the TDL3600-DL offers IP20-rated protection and integrated LED status indicators for quick power and connection diagnostics. This transmission link is essential for maintaining signal integrity in interventional suites, operating rooms, and diagnostic clinics where distance and image precision are critical.
