Barco Nexxis MNA-420 ENC -H / DEC -H
- • Barco Nexxis MNA-420 / MNA420 HDMI Video-over-IP Adapters
- • 24V DC output
- • Low leakage current
- • Sales, replacement and exchange
- • Part# MNA-420 / MNA420, Sales and Exchange
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Barco Nexxis MNA-420 (MNA420) HDMI Video-over-IP Adapters. Ampronix offers new and refurbished Barco Nexxis MNA-420 units for sales, replacement and exchange. Both the MNA-420 and MNA420 model numbers are supported.
Manufacturer: Barco, Model: Nexxis MNA-420 ENC -H (encoder) and MNA-420 DEC -H (decoder), Part numbers: K9303320 (ENC -H), K9303331 (DEC -H)
The Barco Nexxis MNA-420 (MNA420) is a pair of medical network adapters that carry HDMI video over IP inside a digital or hybrid operating room. The MNA-420 ENC -H (K9303320) converts HDMI 2.0 sources into Nexxis IP streams, and the MNA-420 DEC -H (K9303331) converts those uncompressed IP streams back to HDMI for displays.
Key capabilities
- MNA-420 ENC -H (K9303320): 2x HDMI 2.0 inputs, up to 1920x1200p60 per input channel
- Two uncompressed HD streams travel over a single 10GbE fiber link with SFP+ module
- MNA-420 DEC -H (K9303331): 2x HDMI 2.0 outputs, up to 1920x1200p60 on each, or 4096x2160p60 on one output
- Converts uncompressed IP video to HDMI with sub-frame latency
- USB, stereo audio, and GPIO connections carry non-video signals alongside the video
- External 12Vdc medical-grade power supply, 100-240VAC input, 25W maximum consumption
Where it is used
The Barco MNA-420 ENC -H and DEC -H are used in Barco Nexxis operating room networks, where HDMI video from laparoscopy, arthroscopy, and other endoscopy camera systems is routed over IP to surgical displays, boom monitors, and control rooms in digital and hybrid ORs. The encoder sits at the video source and the decoder sits at the display, so video is carried over a fiber network instead of point-to-point video cabling.
System components and compatible part numbers
- MNA-420 ENC -H (encoder): K9303320 - HDMI 2.0 video to Nexxis IP
- MNA-420 DEC -H (decoder): K9303331 - Nexxis IP to HDMI 2.0 video
Specifications at a glance
- ENC -H: 2x HDMI 2.0 in, 1x 10GbE fiber (SFP+) out, 15W typical, 25W maximum
- DEC -H: 1x 10GbE fiber (SFP+) in, 2x HDMI 2.0 out, 17W typical, 25W maximum
- Dimensions: 35 x 103 x 131 mm (1.4 x 4.1 x 5.2 in), Weight: 0.4 kg (0.88 lb)
- Part numbers K9303320 (ENC -H) and K9303331 (DEC -H), models MNA-420 / MNA420
Model: MNA-420 / MNA420
Related: Barco products, Video Solutions.
Frequently asked questions about the Barco Nexxis MNA-420
Is the Barco Nexxis MNA-420 HDMI Video-over-IP Adapters available for sales, replacement and exchange?
Yes. Ampronix offers new and refurbished units of the Barco Nexxis MNA-420, plus replacement and exchange, subject to availability. Both the MNA-420 and MNA420 versions are covered. Call Ampronix for current availability and a quote.
Where can I buy a Barco Nexxis MNA-420 HDMI Video-over-IP Adapters?
Ampronix sells the Barco Nexxis MNA-420 (MNA420). Call Ampronix for current availability, pricing and lead time.
Can I exchange or replace my MNA-420?
Yes. Ampronix offers replacement and exchange options for the MNA-420. Call Ampronix to confirm availability and pricing.
Is the MNA-420 the same as the MNA420?
Yes. MNA-420 and MNA420 are two ways of writing the same model number, and Ampronix supplies both.
What should I have ready when I request a quote for the MNA-420?
Have the model number (MNA-420 or MNA420) and the quantity you need, and whether you need a unit or an exchange. Ampronix will confirm availability and pricing.
What are the key features of the Barco Nexxis MNA-420?
Key points for the Barco Nexxis MNA-420: 2x HDMI 2.0 In, 1920x1200p60, 10GbE Fiber; ENC -H K9303320, DEC -H K9303331; DEC -H: 2x HDMI 2.0 Out, Up to 4096x2160p60; Uncompressed IP Video, Sub-Frame Latency. Call Ampronix to confirm details for your application.
What is the difference between the Barco MNA-420 ENC -H and DEC -H?
The ENC -H (K9303320) is the encoder that takes HDMI 2.0 video in and puts it on the IP network. The DEC -H (K9303331) is the decoder that takes IP video off the network and outputs HDMI 2.0. An OR video path normally needs one of each.
What is the difference between the Barco MNA-420 and MNA-440?
The MNA-420 ENC -H uses a single 10GbE fiber connection to carry two HD streams, while the MNA-440 ENC -H uses two 10GbE fiber connections and handles up to 4096x2160p60 on a single input.
